Bistabile switches
Example of the switch design:
Table A5 - Roll-Control2 - Bistabile switches
Parameter:
20. Switch type
Description:
This parameter determines which switch types and mode S1 and S2 inputs
operate with.
Set value:
3 - Bistable switches
Parameter:
151. Roller blind, Awning, Pergola or Curtain
Description:
1×click (circuit closed)
Next click on the same
same switch (circuit opened)
Available values:
0
Parameter:
151. Venetian blind
Description:
1×click (circuit closed)
Next click on the same
same switch (circuit opened)
Available values:
1 or 2
Favorite position – unavailable
Single bistabile switch
Example of the switch design:
Table A6 - Roll-Control2 - Single bistable switch
Parameter:
20. Switch type
Description:
This parameter determines which switch types and mode S1 and S2 inputs
operate with.
Set value:
4 - Single bistable switch
Parameter:
151. Roller blind, Awning, Pergola or Curtain
Description:
1×click
Next click
One more click
Next click
Available values:
0
Parameter:
151. Venetian blind
Description:
1×click
Next click
One more click
Next click
Available values:
1 or 2
Favorite position – unavailable
10
- Initiate movement to the limit position
- Stop
- Initiate movement to the limit position
- Stop
- Initiate movement to the limit position
- stop
- Initiate movement to the opposite limit position
- stop
- Initiate movement to the limit position
- stop
- Initiate movement to the opposite limit position
- stop
