Nice SPA30 Installation Instructions Manual

Electronic control unit for spider 6060, spider 6065, spider 6100 actuators
Hide thumbs
Table of Contents

Advertisement

Quick Links

I
Centrale
Electronic
elettronica di
control unit for:
controllo per
SPIDER 6060
attuatori:
SPIDER 6065
SPIDER 6060
SPIDER 6100
SPIDER 6065
actuators
SPIDER 6100
Manuale
Installation
d'istruzione
instruction manual
per installazione
QUESTO LIBRETTO È DESTINATO SOLO ALL'INSTALLATORE.
L'installazione dovrà essere effettuata solamente da personale professionalmente qualificato in conformità a quanto previsto dalla
legge n° 46 del 5 marzo 1990 e successive modifiche ed integrazioni e nel pieno rispetto delle norme UNI 8612.
GB
Centrale
électronique de
contrôle pour
pédateurs:
SPIDER 6060
SPIDER 6065
SPIDER 6100
Manuel
d'instructions
pour l'installation
F
D
Elektronische
Steuerzentrale
für die Antriebe:
SPIDER 6060
SPIDER 6065
SPIDER 6100
Installation-
sanleitungen
V. 006
E
Central
electrónica de
control para los
accionadores:
SPIDER 6060
SPIDER 6065
SPIDER 6100
Manual de
instrucciones
para la instalación

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPA30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nice SPA30

Summary of Contents for Nice SPA30

  • Page 1 V. 006 Centrale Electronic Centrale Elektronische Central elettronica di control unit for: électronique de Steuerzentrale electrónica de controllo per SPIDER 6060 contrôle pour für die Antriebe: control para los attuatori: SPIDER 6065 pédateurs: SPIDER 6060 accionadores: SPIDER 6060 SPIDER 6100 SPIDER 6060 SPIDER 6065 SPIDER 6060...

  • Page 2: Table Of Contents

    • PrEN 12445 (Safety in using motorised doors - testing methods) Nice products are designed and manufactured to meet all current European standards and it is essential that the installer also installs the equipment in accordance with all local and European requirements.

  • Page 3: Introduction

    The 433.92 Mhz radio receiver built into the control unit is suitable for the Flo1, Flo2, Flo4 and Very VE transmitters; the code is memorised with the self-learning technique. As an alternative to the built-in radio the unit will accept any of the range of plug-in Nice radio receivers The unit has been designed to guarantee maximum reliability, safety and flexibility of use 1.1) DESCRIPTION:...

  • Page 4: Installation

    English 2.1) INSTALLATION: Read all the instructions through at least once! Before starting installation, carefully analyse all the risks relating to the automation you are about to install. Verify that the door to be automated is in a sound condition and that the mechanics are in good working order, observe the safety margins and minimum distances.

  • Page 5: Description Of Connections

    • The output for powering accessories on terminals 3 and 4 has a direct current ( 3 = negative - , 4 = positive + ); pay attention to polarity when connecting the accessories. ATTENTION: the direct current supply on the photocells made by Nice does not allow synchronised functioning (an alternate current supply is needed) .

  • Page 6: Adjustments

    English D) Now carry out a test with the door disconnected from the motor, making it open and close, and press the STEP-BY-STEP button to verify that the mechanical parts are all in good working order. (Door OPEN is the first manoeuvre after power is turned back on.) When the cycle has finished hook the door back on the chain.

  • Page 7: Functioning Modes

    English ✓ The unit carries out a braking procedure during the closing manoeuvre that slows speed and reduces noise in the final movement phase. Fig.5 The point at which slowing down starts is calculated automatically according to the length of the previous ma - noeuvre;...

  • Page 8: Self-Learning Radio " 16

    4.1 ADDING AN ALTERNATIVE RADIO: There is a supplementary connector on the card for plugging in Nice RADIO receivers as an alternative to the radio already included on the card. We recommend waiting until installation is complete before plugging in any alternative RADIO card and only after having verified that the system works.

  • Page 9: Technical Data " 17

    Decoding : digital (4096 combinations) suitable for FLO1, FLO2. FLO4 trasmitter. Nice SPA reserves the right to modify its products at any time without prior notice. FINAL NOTES: This manual is only for use by technical personnel qualified to carry out the installation.
