IP Address Settings
IP Mode
IP Address
Subnet Mask
Gateway
DNS 1 and 2
Click Save to store the settings as entered. Once saved, they are held as Pending. To complete the
process, Reboot the iBoot-PDU. When the iBoot-PDU is ready for reboot, a notification will appear at the
top left of the information panel. Click on notifications, then reboot.
6.6.

Web

Sets the features regarding the internal web server of the iBoot-PDU
Web Server Settings
Web Enabled
Web Port
SSL Enabled
SSL Port
Note: Ports 8888, 8889, 8890, 8891, 8892, 8893, 8894, 8895, 8896, 8897, 9090, 8898 and 8899 are
reserved for internal use by the iBoot-PDU. Do not use these ports for any other setting.
6.7.

DxP

The iBoot-PDU supports Dataprobe's proprietary Device Management Protocol (DxP). The DxP allows
interoperability between multiple Dataprobe products.
The iBoot-PDU will respond to DxP commands from products such the IPIO series, iBoot-G2 series, the
DxP Command Utility or your own software supporting DxP. The DxP protocol and supporting documents
can be found at
http://dataprobe.com/support/shared/dxp_proto_1.2_v101118e.pdf
iBoot-PDU_v230829w
Sets the mode that will select the IP Address settings:
DHCP: The iBoot-PDU will get these settings from a DHCP Server
STATIC: The iBoot-PDU will used the settings as manually set below:
Enter the IP Address [XXX.XXX.XXX.XXX]
Enter the Subnet Mask [XXX.XXX.XXX.XXX]
Enter the Gateway [XXX.XXX.XXX.XXX]
Enter two DNS server entries [XXX.XXX.XXX.XXX] (enter the same address for
both if you only have one DNS available)
Enables [True] or disables [False] the web server
Sets the IP Port the web server will use.
Enables [True] or disables [False] Secure Sockets Layer. When true, web clients
must use https:// to connect to the iBoot-PDU
Sets the IP Port the web server will use for SSL
iBoot-PDU User Manual Page 28
