Restart Delay Sets the length of time in seconds, to delay after initiating an action before
beginning to restart the pinging tests. Allows time for rebooted equipment to
initialize. 0 – 999 seconds is valid.
Address Set the IP address or Fully Qualified Domain Name (FQDN) (i.e. example.com)
of the target of the pinging.
Set the frequency of the pinging, in seconds. 1 – 999 is valid.
Period
Fail Count Set the number of times the ping test must fail consecutively, in order to trigger
the action.
Sets the length of time iBoot-PDU will wait for each ping response. The default
Timeout
2 seconds should only be changed in applications where the normal response
time is expected to be extended, such as in satellite communications.
Outlet / Action Set the outlet that this trigger will act upon. This setting allows quick definition of
a single outlet sequence. All Outlets is also available. When more complex
sequences are required, select Use Advanced Settings button.
Action Set the action on the single outlet, or all outlets:
On
Off
On-Follow
Off- Follow
Cycle
Cycle / Forever When Cycle is selected, sets the maximum times the outlet(s) will cycle (1-60). If
an unlimited number of cycles is preferred, use the Forever checkbox.
Advanced Settings The Advanced Settings allows a Fail and Clear Sequence to be defined. Select
one of the previously defined sequences from the drop down list. If None is
selected for both, the trigger will be informational only and no action will be
taken. The sequence can be repeated using the cycle count setting (1-60). The
Clear sequence will only run one time.
Save Click Save to complete the setup process.
iBoot-PDU_v230829w
Turn the outlet On, make no change when Clear
Turn the outlet Off, make no change when Clear
Turn the outlet On when Fail and Off when Clear
Turn the outlet Off when Fail and On when Clear
Cycle the outlet for the programmed length of time.
Cycle can be in either direction (On-OFF-ON or Off-On-
Off depending on the current state of the outlet. For a
more determinate cycle, use a sequence with two or
more steps
