Update - Dataprobe iBoot-PDU4-N15 Manual

Rsyslog Setup
Click on Add Rsyslog button to open the Add Rsyslog Manager setup card.
Manager Name
Manager IP
Address
TCP/UDP
Port
Enable
Click Save to store the settings
Note: Ports 8888, 8889, 8890, 8891, 8892, 8893, 8894, 8895, 8896, 8897, 9090, 8898 and 8899 are
reserved for internal use by the iBoot-PDU. Do not use these ports for any other setting.
8.6.

Update

The iBoot-PDU firmware can be updated and custom firmware can be installed. Upon selection, the iBoot-
PDU checks for new and available version of the firmware. Connection to the Internet is required for this
function. Firmware can also be added from a file, provided by Dataprobe.
There is a CLI method to upgrade as well described in section 9.3.18
Install new firmware
Click on the desired version and then Install New Software. If Local firmware is selected navigate to the
desired file, or use drag and drop to load the file. Click on INSTALL NEW SOFTWARE to begin the
installation process.
Do not navigate away from the Update page until the process is complete.
iBoot-PDU_v230829w
Enter a name for the Remote Syslog manager
Enter the IP Address of the manager
Select either TCP or UDP protocol
Set the port for the Syslog manager [default: 514 ]
Select Enable or Disable for the Syslog reporting
iBoot-PDU User Manual Page 45
