Integration into BACnet Systems

8.3. Integration into BACnet Systems
NOTICE
You can consult the Protocol Implementation Conformance Statement (PICS) document here.

8.3.1. BACnet Objects

NOTICE
This part is common for BACnet MS/TP and BACnet/IP.
Input object types:
• Binary input
Output object types:
• Binary output
• Multistate output
• Analog output
The following tables list all available BACnet objects for this gateway.
Table 8. Error signals
Object name
OUXX_Communication Error OU
OU Addressing Error
Table 9. Global signals
Object name
On/Off (all units)
Mode (all units)
FanSpeed (all units)
Vane position swing (all units)
Temperature Setpoint (all units)
USER MANUAL Version 1.0.12
Possible values
0: No error
1: Error
0: OU Addressing OK
1: Manual Addr in OU required
Possible values
0: Off
1: On
1: Heat
2: Cool
3: Fan
4: Dry
5: Auto
6: Cool Storage
7: Heat Storage
1: Low
2: Mid
3: High
4: Auto
0: Swing Off
1: Swing On
Cool: 18 .. 30°C / 64 .. 86°F
Heat: 16 .. 30°C / 61 .. 86°F
700series Air Gateway - IN770AIR⁎⁎⁎O000
Object type Object instance
3-Binary Input OU[0..15] + 1
3-Binary Input 0 + 16
Object type Object instance
4-Binary Output 0 + 0
14-Multistate Output 0 + 0
14-Multistate Output 0 + 1
4-Binary Output 0 + 1
1-Analog Output 0 + 0
