Nameplate - SEW-Eurodrive MOVIPRO PHE B-A15-1X0 B-00 Series Operating Instructions Manual

Device structure
4

Nameplate

4.5 Nameplate
30
Operating Instructions – MOVIPRO
The nameplate lists information about the device type. The following figure shows an
example of a nameplate:
SO#:
Eingang / Input
D-76646 Bruchsal U =
I =
Made in Germany
f =
[2]
T =
[1]
XX XX XX
[1] Product name
[2] UKCA representative
[3] Designation according to WEEE directive
[4] CE marking
[5] RCM approval
[6] China RoHS-2 marking
[7] UKCA marking
[8] UL approval (depending on device certification)
[9] EAC marking
Depending on the device design, the following information is listed on the nameplate:
Value Specification
Type Type designation
SO# Production number
U Voltage
I Current
f Frequency
T Ambient temperature
P Rated output power
IP Degree of protection
XX XX XX Status line
ML XXXX Production plant
®
PHE..B-A15-.1X0..B-00
Type:
Ausgang / Output
P =
[3] [4] [5] [6] [7]
50
IP
ML XXXX
27021626497529995
[8]
[9]
