Rosco Dual-Vision XC4 Install Manual

For ford f-150
Hide thumbs Also See for Dual-Vision XC4:

Advertisement

Quick Links

Download this manual
2004-2008 Ford F-150 Install Guide
This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2004-2008 Ford F150.
Please review the Installation Guidelines for grounding and making connections prior to installing. In this
guide you will find dash removal, wire locations, & mounting locations.
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
vehicle has any damage
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
accidental shorts or blown fuses
th,
UPDATED October 15
2018
***NEW PART***
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Techsupport@Roscovision.com
Blue – Extra Installation Parts Needed
Gray – Installation Warning
Purple – New Installation
Red – Urgent Warning
Version 4.10.2
Proprietary and Confidential
2004-2008 Ford F-150

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 2004-2008 Ford F-150 Install Guide This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2004-2008 Ford F150. Please review the Installation Guidelines for grounding and making connections prior to installing. In this guide you will find dash removal, wire locations, & mounting locations.
  • Page 2 2004-2008 Ford F-150 Install Guide Before starting your install, its best to prep the windshield for recorder mounting Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield...
  • Page 3 2004-2008 Ford F-150 Install Guide Installation Layout: Before starting your installation, please take note of component mounting locations. Follow the blue arrow for recorder cable routing Version 4.10.2 Proprietary and Confidential 2004-2008 Ford F-150...

  • Page 4: Step 1 - Dash Removal

    2004-2008 Ford F-150 Install Guide Step 1 - Dash Removal: • Start by removing the side panel with a panel tool (Photo A) • Remove the two 7MM bolts located at the bottom the dash panel (Photo B) Version 4.10.2 Proprietary and Confidential 2004-2008 Ford F-150...
  • Page 5 2004-2008 Ford F-150 Install Guide Dash Removal Continued: • Using a panel tool, pry the lower dash off (Photo A) • Remove the four 8MM Bolts securing the metal dash brace (Photo B) Version 4.10.2 Proprietary and Confidential 2004-2008 Ford F-150...

  • Page 6: Step 2 - Power Connections

    2004-2008 Ford F-150 Install Guide Step 2 - Power Connections: • The Constant & Ignition wires are located at the ignition harness (Black 7 Pin Plug) • Connect the RED constant wire to the vehicles Green/Violet wire (Pin 4) • Connect the YELLOW ignition wire to the vehicles Blue/Green wire (Pin 1) Version 4.10.2 Proprietary and Confidential...

  • Page 7: Step 3 - Antenna Mounting

    2004-2008 Ford F-150 Install Guide Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 8 2004-2008 Ford F-150 Install Guide Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) •...
  • Page 9 2004-2008 Ford F-150 Install Guide Step 5 - PDC & Modem Mounting Locations: • The PDC and modem are in the cavity on the left side of the dash (Photo A) • The Modem is secured to the metal brace with two self-taping screws (Photo B) •...
  • Page 10 2004-2008 Ford F-150 Install Guide Step 6 - Camera Mounting and wire Routing: Large truck with split window Small Passenger Vehicle Factory Sensor under Mirror Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A). If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a distraction to the driver (Photo B).
  • Page 11 2004-2008 Ford F-150 Install Guide To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 4.10.2 Proprietary and Confidential 2004-2008 Ford F-150...
