Rosco Dual-Vision XC4 Installation Manual

For 2018 kenworth t880
Hide thumbs Also See for Dual-Vision XC4:
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
2018 Kenworth T880
This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2018 Kenworth T880 Truck.
Please review the Installation Guidelines for grounding and making connections prior to installing. In this
guide you will find dash removal, wire locations, & mounting locations.
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
vehicle has any damage
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
accidental shorts or blown fuses
th,
UPDATED October 15
2018
***NEW PART***
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Techsupport@Roscovision.com
Blue – Extra Installation Parts Needed
Gray – Caution
Purple – New Installation
Red – Warning
Version 4.10.2
Proprietary and Confidential
2018 Kenworth T880

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 2018 Kenworth T880 This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2018 Kenworth T880 Truck. Please review the Installation Guidelines for grounding and making connections prior to installing. In this guide you will find dash removal, wire locations, & mounting locations.
  • Page 2 2018 Kenworth T880 Before starting your install, its best to prep the windshield for recorder mounting Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield IMPORTANT: VHB Tape should only be applied when windshield temperature is within 50°F-...

  • Page 3: Step 1 - Dash Removal

    2018 Kenworth T880 Step 1 - Dash Removal: • Locate the CB Radio housing on the top storage compartments (Photo A) • Push down on the radio release button and pull the tray out (Photo B) Version 4.10.2 Proprietary and Confidential 2018 Kenworth T880...

  • Page 4: Step 2 - Power Connections

    2018 Kenworth T880 Step 2 - Power Connections: • Locate the three pin Brown CB Radio plug on the CB Radio harness (Photo A) • Connect the RED CONSTANT wire to the vehicles RED wire • Connect the YELLOW IGNITION wire to the vehicles ORANGE wire Version 4.10.2 Proprietary and Confidential 2018 Kenworth T880...

  • Page 5: Step 3 - Antenna Mounting

    2018 Kenworth T880 Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 6 2018 Kenworth T880 Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) • Make these connections prior to mounting the modem &...
  • Page 7 2018 Kenworth T880 Step 5 - PDC & Modem Mounting: • Using a panel tool, carefully pry the CB Radio trim panel (Photo A) • Secure the PDC & Modem behind the left storage pocket (Photo B) Make sure all extra wire slack is stored away from the CB Radio cavity! Secure all wires with zip ties behind...
  • Page 8 2018 Kenworth T880 Step 6 - Camera Mounting and wire Routing: Large truck with split window Factory Sensor under Mirror Small Passenger Vehicle Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A). If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a distraction to the driver (Photo B).
  • Page 9 2018 Kenworth T880 To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 4.10.2 Proprietary and Confidential 2018 Kenworth T880...
