Rosco Dual-Vision XC4 Installation Manual

For 2016-2017 mack truck
Hide thumbs Also See for Dual-Vision XC4:

Advertisement

Quick Links

Download this manual
2016-2017 Mack Truck Installation Guide
This guide will show the proper procedures to install a Dual-Vision XC4 Camera in a 2016-2017 Mack
Truck. Please review the Installation Guidelines for grounding and making connections prior to installing.
For Technical Support please contact our support team at:
Techsupport@Roscovision.com
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
vehicle has any damage
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
accidental shorts or blown fuses
th,
UPDATED October 15
2018
***NEW PART***
***Harness DV457 is needed if trigger wires are being connected***
Blue – Extra Installation Parts Needed
Gray – Caution
Purple – New Installation
Red – Warning
Version 4.10.2
2016-2017 Mack Truck
Proprietary and Confidential

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 2016-2017 Mack Truck Installation Guide This guide will show the proper procedures to install a Dual-Vision XC4 Camera in a 2016-2017 Mack Truck. Please review the Installation Guidelines for grounding and making connections prior to installing. For Technical Support please contact our support team at: Techsupport@Roscovision.com...
  • Page 2 2016-2017 Mack Truck Installation Guide Before starting your install, its best to prep the windshield for recorder mounting Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield...

  • Page 3: Step 1 - Dash Removal

    2016-2017 Mack Truck Installation Guide Step 1 – Dash Removal: • The vehicles power connections & mounting location will be found on top of the center console (Photo A) under the fuse panel cover • Remove the three T-30 screws securing the fuse panel cover (Photo B) Version 4.10.2 2016-2017 Mack Truck Proprietary and Confidential...

  • Page 4: Step 2- Power Connections

    2016-2017 Mack Truck Installation Guide Step 2- Power Connections: • The Constant, Ignition, & Ground connections are in the fuse box, on the terminal panel. (Photo • Crimp ring terminals on the constant, ignition, & ground wires of the DVXC4 Recorder power harness (Photo D) Version 4.10.2 2016-2017 Mack Truck...
  • Page 5 2016-2017 Mack Truck Installation Guide Power Connections (Continued) • Connect the Yellow ignition wire to the first Ignition terminal • Connect the Red constant wire to the 2 terminal, & connect the Black Ground wire to the 8 terminal (Photo E) Version 4.10.2 2016-2017 Mack Truck Proprietary and Confidential...

  • Page 6: Step 3 - Antenna Mounting

    2016-2017 Mack Truck Installation Guide Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 7 2016-2017 Mack Truck Installation Guide Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) •...
  • Page 8 2016-2017 Mack Truck Installation Guide Step 5 - PDC & Modem Mounting Location: • The PDC & the Modem are in the fuse box compartment, zip tied to the factory harness • Neatly Bundle up excess cabling with a zip tie and tie it to a factory harness, or panel – This is very important when working on heavy equipment vehicles.
  • Page 9 2016-2017 Mack Truck Installation Guide Step 6 - Recorder Mounting: Large truck with split window Factory Sensor under Mirror Small Passenger Vehicle Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A). If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a distraction to the driver (Photo B).
  • Page 10 2016-2017 Mack Truck Installation Guide To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 4.10.2 2016-2017 Mack Truck Proprietary and Confidential...
