Rosco Dual-Vision XC4 Installation Manual

For 2018 chevy equinox
Hide thumbs Also See for Dual-Vision XC4:

Advertisement

Quick Links

Download this manual
2018 Chevy Equinox Installation Guide
This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2018 Chevy Equinox. Please
review the Installation Guidelines for grounding and making connections prior to installing. In this guide
you will find dash removal, wire locations, & mounting locations.
This guide is for Push to Start vehicles only!
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
accidental shorts or blown fuses
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
vehicle has any damage
th,
UPDATED October 15
2018
***NEW PART***
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Techsupport@Roscovision.com
Blue – Extra Installation Parts Needed
Gray – Installation Warning
Purple – New Installation
Red – Urgent Warning
Version 2.2.2
