Rosco Dual-Vision XC4 Installation Manual

2008-2012 jeep liberty
Hide thumbs Also See for Dual-Vision XC4:

Advertisement

Quick Links

Download this manual
2008-2012 Jeep Liberty Install Guide
This guide will show the proper procedures to install a Dual-Vision XC4 Camera in a 2008-2012 Jeep
Liberty. Please review the Installation Guidelines for grounding and making connections prior to
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Gray – Caution
Red – Warning
Version 4.10.2
Proprietary and Confidential
installing.
accidental shorts or blown fuses
vehicle has any damage
th,
UPDATED October 15
***NEW PART***
Techsupport@Roscovision.com
2008-2012 Jeep Liberty
2018
Blue – Extra Installation Parts Needed
Purple – New Installation

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 2008-2012 Jeep Liberty Install Guide This guide will show the proper procedures to install a Dual-Vision XC4 Camera in a 2008-2012 Jeep Liberty. Please review the Installation Guidelines for grounding and making connections prior to installing. After testing and verifying power wires, disconnect the negative battery terminal to prevent any accidental shorts or blown fuses Verify no vehicle service lights are on prior to installation.
  • Page 2 2008-2012 Jeep Liberty Install Guide Before starting your install, its best to prep the windshield for recorder mounting Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield...

  • Page 3: Step 1 - Dash Removal

    2008-2012 Jeep Liberty Install Guide Step 1 – Dash Removal: • Using a panel tool, carefully pry the dash panel and pull down. This will release and drop the lower dash (Photo A) Version 4.10.2 Proprietary and Confidential 2008-2012 Jeep Liberty...

  • Page 4: Step 2- Power Connections

    2008-2012 Jeep Liberty Install Guide Step 2- Power Connections: • The constant & ignition wires are located at the 5-pin ignition harness plug • Connect the RED constant wire to the vehicles Lt Blue/Red Wire (Pin 5) • Connect the YELLOW ignition wire to the vehicles Pink/White Wire (Pin 3) Version 4.10.2 Proprietary and Confidential 2008-2012 Jeep Liberty...

  • Page 5: Step 3 - Antenna Mounting

    2008-2012 Jeep Liberty Install Guide Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 6 2008-2012 Jeep Liberty Install Guide Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) •...
  • Page 7 2008-2012 Jeep Liberty Install Guide Step 5 - Modem & PDC Mounting: • The Modem is located on the left side of the lower dash • Secure the modem to the factory harness with a zip tie • Make sure the modem is behind the wire harness. Make sure the pocket doesn’t interfere with the wires (Blue Arrow) Version 4.10.2 Proprietary and Confidential...
  • Page 8 2008-2012 Jeep Liberty Install Guide Modem & PDC Mounting (Continued): • The PDC is located on the right side of the lower dash • Secure the PDC with a zip tie to the factory brace and harness IT’S IMPORTANT TO NEATLY ZIP TIE WIRES TO A FACTORY BRACKET OR HARNESS TO PREVENT FROM FALLING.

  • Page 9: Step 6 - Wire Routing

    2008-2012 Jeep Liberty Install Guide Step 6 – Wire Routing: • Bundle up the extra wire and zip tie it to the factory bracket or harness in the top of the dash cavity • Follow factory wires when routing and stay clear of steering wheel tilt, or parking brake mechanism •...
  • Page 10 2008-2012 Jeep Liberty Install Guide Step 7 - Recorder Mounting: Large truck with split window Factory Sensor under Mirror Small Passenger Vehicle Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A). If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a distraction to the driver (Photo B).
  • Page 11 2008-2012 Jeep Liberty Install Guide To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 4.10.2 Proprietary and Confidential 2008-2012 Jeep Liberty...
