Rosco Dual-Vision XC4 Install Manual

For 2008-2018 chevy express van
Hide thumbs Also See for Dual-Vision XC4:

Advertisement

Table of Contents

2008-2018 Chevy Express Van Install Guide
This guide will show the proper procedures to install a Dual-Vision XC4 Camera in a 2008-2018 Chevy
Express Van. Please review the Installation Guidelines for grounding and making connections prior to
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Gray – Caution
Red – Warning
Version 4.10.2
Proprietary and Confidential
installing.
accidental shorts or blown fuses
vehicle has any damage
th,
UPDATED October 15
***NEW PART***
Techsupport@Roscovision.com
2008-2018 Chevy Express Van
2018
Blue – Extra Installation Parts Needed
Purple – New Installation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 2008-2018 Chevy Express Van Install Guide This guide will show the proper procedures to install a Dual-Vision XC4 Camera in a 2008-2018 Chevy Express Van. Please review the Installation Guidelines for grounding and making connections prior to installing. After testing and verifying power wires, disconnect the negative battery terminal to prevent any accidental shorts or blown fuses Verify no vehicle service lights are on prior to installation.
  • Page 2 2008-2018 Chevy Express Van Install Guide Before starting your install, its best to prep the windshield for recorder mounting Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield...

  • Page 3: Step 1 - Dash Removal

    2008-2018 Chevy Express Van Install Guide Step 1 – Dash Removal: • Remove the two 10MM Bolts located on both sides of the lower dash (Photo A) • Using a panel tool, carefully pry the lower dash panel and remove (Photo B) Version 4.10.2 Proprietary and Confidential 2008-2018 Chevy Express Van...

  • Page 4: Step 2- Power Connections

    2008-2018 Chevy Express Van Install Guide Step 2- Power Connections: • The Constant & Ignition wires are located at the Junction plug in the center of the lower dash • Connect the RED constant wire to the vehicles Red/White wire •...

  • Page 5: Step 3 - Antenna Mounting

    2008-2018 Chevy Express Van Install Guide Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 6 2008-2018 Chevy Express Van Install Guide Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) •...
  • Page 7 2008-2018 Chevy Express Van Install Guide Step 5 - Modem & PDC Mounting: • The Modem is mounted on the left side of the lower dash, behind the headlight controls. • Secure the modem to the harness with a zip tie Version 4.10.2 Proprietary and Confidential 2008-2018 Chevy Express Van...
  • Page 8 2008-2018 Chevy Express Van Install Guide Modem & PDC Mounting (Continued): • The PDC is located behind the center console, with access on the right side of the lower dash • Secure the PDC to the large loom factory harness Version 4.10.2 Proprietary and Confidential 2008-2018 Chevy Express Van...

  • Page 9: Step 6 - Wire Routing

    2008-2018 Chevy Express Van Install Guide IT’S IMPORTANT TO NEATLY ZIP TIE WIRES TO A FACTORY BRACKET OR HARNESS TO PREVENT FROM FALLING. KEEP AWAY FROM THE STEERING FUNCTIONS AND ANY MOVING PARTS Step 6 – Wire Routing: • Bundle up the extra wire and zip tie it to the factory bracket or harness in the top of the dash cavity •...
  • Page 10 2008-2018 Chevy Express Van Install Guide Step 7 - Recorder Mounting: Large truck with split window Factory Sensor under Mirror Small Passenger Vehicle Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A). If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a distraction to the driver (Photo B).
  • Page 11 2008-2018 Chevy Express Van Install Guide To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 4.10.2 Proprietary and Confidential 2008-2018 Chevy Express Van...
