Rosco Dual-Vision XC4 Installation Manual

2007-2014 chevy tahoe/suburban/gmc yukon
Hide thumbs Also See for Dual-Vision XC4:

Advertisement

Quick Links

Download this manual
2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide
This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2007-2014 Chevy
Tahoe/Suburban/GMC Yukon. Please review the Installation Guidelines for grounding and making
connections prior to installing. In this guide you will find dash removal, wire locations, & mounting
locations.
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
vehicle has any damage
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
accidental shorts or blown fuses
th,
UPDATED October 15
2018
***NEW PART***
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Techsupport@Roscovision.com
Blue – Extra Installation Parts Needed
Gray – Installation Warning
Purple – New Installation
Red – Urgent Warning
Version 4.10.2
Proprietary and Confidential
2007-2014 Chevy Tahoe/Suburban/GMC Yukon

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2007-2014 Chevy Tahoe/Suburban/GMC Yukon. Please review the Installation Guidelines for grounding and making connections prior to installing. In this guide you will find dash removal, wire locations, & mounting locations.
  • Page 2 2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide Before starting your install, its best to prep the windshield for recorder mounting Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield...

  • Page 3: Step 1 - Dash Removal

    2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide Step 1 - Dash Removal: • Start by removing the side panel with a panel tool (Photo A) Version 4.10.2 Proprietary and Confidential 2007-2014 Chevy Tahoe/Suburban/GMC Yukon...
  • Page 4 2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide Dash Removal Continued: • Remove the two philips screws located on the bottom of the dash panel • Remove the 10MM bolt under the hood release latch Version 4.10.2 Proprietary and Confidential 2007-2014 Chevy Tahoe/Suburban/GMC Yukon...
  • Page 5 2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide Dash Removal (Continued): • Using a panel tool, remove the steering wheel tilt latch (Photo A) • Remove the two Philips screws on the lower steering wheel panel (Photo B) Version 4.10.2 Proprietary and Confidential 2007-2014 Chevy Tahoe/Suburban/GMC Yukon...

  • Page 6: Step 2 - Power Connections

    2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide Step 2 - Power Connections: • The Constant wire is located behind the fuse panel • Connect the RED constant wire to the vehicles RED/BLACK wire Version 4.10.2 Proprietary and Confidential 2007-2014 Chevy Tahoe/Suburban/GMC Yukon...
  • Page 7 2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide Power Connections (Continued): • The ignition wire is located at the ignition switch harness • Connect the yellow ignition wire to the vehicles PINK wire Version 4.10.2 Proprietary and Confidential 2007-2014 Chevy Tahoe/Suburban/GMC Yukon...

  • Page 8: Step 3 - Antenna Mounting

    2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 9 2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) •...
  • Page 10 2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide Step 5 - PDC & Modem Mounting Locations: • The PDC is located to the right of the fuse box. Secure with a zip tie around the factory harness • The Modem can be mounted on the right side of the lower dash •...
  • Page 11 2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide Step 6 - Recorder Mounting and wire Routing: Large truck with split window Factory Sensor under Mirror Small Passenger Vehicle Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A).
  • Page 12 2007-2014 Chevy Tahoe/Suburban/GMC Yukon Install Guide To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 4.10.2 Proprietary and Confidential 2007-2014 Chevy Tahoe/Suburban/GMC Yukon...
