Rosco Dual-Vision XC4 Install Manual

For dodge caravan
Hide thumbs Also See for Dual-Vision XC4:

Advertisement

Quick Links

Download this manual
2008-2018 Dodge Caravan Install Guide
This guide will show the proper procedures to install a Dual-Vision XC4 Camera in a 2008-2018 Chevy
Express Van. Please review the Installation Guidelines for grounding and making connections prior to
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Gray – Caution
Red – Warning
Version 4.10.2
Proprietary and Confidential
installing.
accidental shorts or blown fuses
vehicle has any damage
rd
Revised May 3
, 2018 – Constant wire location changed
UPDATED October 15
***NEW PART***
Techsupport@Roscovision.com
2008-2018 Dodge Caravan
th,
2018
Blue – Extra Installation Parts Needed
Purple – New Installation

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 2008-2018 Dodge Caravan Install Guide This guide will show the proper procedures to install a Dual-Vision XC4 Camera in a 2008-2018 Chevy Express Van. Please review the Installation Guidelines for grounding and making connections prior to installing. After testing and verifying power wires, disconnect the negative battery terminal to prevent any accidental shorts or blown fuses Verify no vehicle service lights are on prior to installation.
  • Page 2 2008-2018 Dodge Caravan Install Guide Before starting your install, its best to prep the windshield for recorder mounting Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield...

  • Page 3: Step 1 - Dash Removal

    2008-2018 Dodge Caravan Install Guide Step 1 – Dash Removal: • Using a panel tool, carefully pry the side panel of the dash and remove (Photo A) • Remove the nylon clip holding the lower dash (Photo B) Version 4.10.2 Proprietary and Confidential 2008-2018 Dodge Caravan...
  • Page 4 2008-2018 Dodge Caravan Install Guide Dash Removal (Continued): • Remove the two nylon clips on both sides of the lower dash panel (Photo A) • Remove the four 7MM bolts securing the metal dash panel (Photo B) DO NOT UNPLUG THE AIRBAG HARNESS! THE AIRBAG IS ATTACHED TO THIS BRACKET. USE CAUTION WHEN REMOVING THIS PANEL Nylon Clip 7MM Bolts...

  • Page 5: Step 2- Power Connections

    2008-2018 Dodge Caravan Install Guide Step 2- Power Connections: • The Constant & Ignition wires are located at the ignition switch harness • Connect the RED constant wire to the vehicles Lt Blue/Red wire • Connect the YELLOW ignition wire to the vehicles Pink/White wire •...

  • Page 6: Step 3 - Antenna Mounting

    2008-2018 Dodge Caravan Install Guide Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 7 2008-2018 Dodge Caravan Install Guide Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) •...
  • Page 8 2008-2018 Dodge Caravan Install Guide Step 5 - Modem & PDC Mounting: • The Modem & PDC are mounted on the left side of the lower dash, behind the headlight controls (Photo A) • Secure the modem to the metal support bracket with a zip tie (Photo B) Version 4.10.2 Proprietary and Confidential 2008-2018 Dodge Caravan...

  • Page 9: Step 6 - Wire Routing

    2008-2018 Dodge Caravan Install Guide IT’S IMPORTANT TO NEATLY ZIP TIE WIRES TO A FACTORY BRACKET OR HARNESS TO PREVENT FROM FALLING. KEEP AWAY FROM THE STEERING FUNCTIONS AND ANY MOVING PARTS Step 6 – Wire Routing: • Bundle up the extra wire and zip tie it to the factory bracket or harness in the top of the dash cavity •...
  • Page 10 2008-2018 Dodge Caravan Install Guide Step 7 - Recorder Mounting: Large truck with split window Factory Sensor under Mirror Small Passenger Vehicle Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A). If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a distraction to the driver (Photo B).
  • Page 11 2008-2018 Dodge Caravan Install Guide To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 4.10.2 Proprietary and Confidential 2008-2018 Dodge Caravan...
