Rosco Dual-Vision XC4 Installation Manual

For 2012-2016 hino 268
Hide thumbs Also See for Dual-Vision XC4:

Advertisement

Quick Links

Download this manual
2012-2016 Hino 268 Installation Guide
This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2012-2016 Hino 268. Please
review the Service Bulletins for grounding and making connections prior to installing. In this guide you
will find dash removal, wire locations, & mounting locations.
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
accidental shorts or blown fuses
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
vehicle has any damage
th,
UPDATED October 15
2018
***NEW PART***
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Techsupport@Roscovision.com
Blue – Extra Installation Parts Needed
Gray – Caution
Purple – New Installation
Red – Warning
Version 4.10.2
Proprietary and Confidential

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 2012-2016 Hino 268 Installation Guide This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2012-2016 Hino 268. Please review the Service Bulletins for grounding and making connections prior to installing. In this guide you will find dash removal, wire locations, &...
  • Page 2 2012-2016 Hino 268 Installation Guide Before starting your install, its best to prep the windshield for recorder mounting Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield...
  • Page 3 2012-2016 Hino 268 Installation Guide Installation Layout Before starting your installation please take note of component mounting locations. Version 4.10.2 Proprietary and Confidential...

  • Page 4: Step 1 - Dash Removal

    2012-2016 Hino 268 Installation Guide Step 1 - Dash Removal: Power connections & Mounting location can be accessed on the passenger side of the truck • Pry the dash starting at the bottom (Photo A) • This will give you access to mounting location of the PDC & the Modem •...

  • Page 5: Step 2 - Power Connections

    2012-2016 Hino 268 Installation Guide Step 2 - Power Connections: • Locate the white 15 pin plug located under the support brace (Photo C) • Connect the RED Constant wire to the vehicle white wire & the YELLOW ignition wire to the vehicles blue wire.

  • Page 6: Step 3 - Antenna Mounting

    2012-2016 Hino 268 Installation Guide Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 7 2012-2016 Hino 268 Installation Guide Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) •...
  • Page 8 2012-2016 Hino 268 Installation Guide Step 5 – PDC & Modem Mounting Location: • The PDC & the Modem are located under the dash panel on the passenger side of the vehicle, on top of the fuse panel. • Using self-tapping screws, mount the PDC & the Modem to the support bracket DO NOT SCREW INTO THE VEHICLES PLASTIC VENT Vehicles Vent PLEASE READ THE RECORDER MOUNTING &...
  • Page 9 2012-2016 Hino 268 Installation Guide Step 6 - Camera Mounting and wire Routing: Large truck with split window Factory Sensor under Mirror Small Passenger Vehicle Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A). If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a distraction to the driver (Photo B).
  • Page 10 2012-2016 Hino 268 Installation Guide To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 4.10.2 Proprietary and Confidential...
