2015-2018 Ford Transit Install Guide
This guide will show the proper procedures to install a Dual-Vision XC4 Camera in a 2015-2018 Ford
Transit. Please review the Installation Guidelines for grounding and making connections prior to
THIS GUIDE IS FOR THE FORD TRANSIT ONLY! NOT THE TRANSIT CONNECT
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Gray – Caution
Red – Warning
Version 4.10.2
Proprietary and Confidential
installing.
accidental shorts or blown fuses
vehicle has any damage
th,
UPDATED October 15
***NEW PART***
Techsupport@Roscovision.com
2015-2018 Ford Transit
2018
Blue – Extra Installation Parts Needed
Purple – New Installation

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 2015-2018 Ford Transit Install Guide This guide will show the proper procedures to install a Dual-Vision XC4 Camera in a 2015-2018 Ford Transit. Please review the Installation Guidelines for grounding and making connections prior to installing. THIS GUIDE IS FOR THE FORD TRANSIT ONLY! NOT THE TRANSIT CONNECT...
  • Page 2 2015-2018 Ford Transit Install Guide Before starting your install, its best to prep the windshield for recorder mounting Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield...

  • Page 3: Step 1 - Dash Removal

    2015-2018 Ford Transit Install Guide Step 1 – Dash Removal: • Using a panel tool, carefully pry the dash panel and pull down. This will release and drop the lower dash (Photo A) Version 4.10.2 Proprietary and Confidential 2015-2018 Ford Transit...
  • Page 4 2015-2018 Ford Transit Install Guide Dash Removal (Continued): • Remove the two T25 screws securing the steering column (Photo A) • Using a panel tool, push in the tabs on both sides of the steering wheel (Photo B) • The vehicle has to be running to remove these tabs. Once you have one side pushed in, turn the steering wheel to access the other side Turn the steering wheel to access the clip on the other side...

  • Page 5: Step 2- Power Connections

    2015-2018 Ford Transit Install Guide Step 2- Power Connections: • The Constant & Ignition wires are located at the black 7-pin ignition harness plug • Connect the RED constant wire to the vehicles Blue/Red Wire (Pin 4) • Connect the YELLOW ignition wire to the vehicles Brown/Yellow Wire (Pin 3) Version 4.10.2 Proprietary and Confidential 2015-2018 Ford Transit...
  • Page 6 2015-2018 Ford Transit Install Guide Power Connections (Continued): • Connect the Black Ground wire to the metal support brace next to the OBD plug. • Be sure to follow the proper grounding procedure explained in the Installation Techniques Guideline Grounding Location Version 4.10.2 Proprietary and Confidential 2015-2018 Ford Transit...

  • Page 7: Step 3 - Antenna Mounting

    2015-2018 Ford Transit Install Guide Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 8 2015-2018 Ford Transit Install Guide Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) •...
  • Page 9 2015-2018 Ford Transit Install Guide Step 5 - Modem & PDC Mounting: • The Modem is located on top of the fuse panel • Attach the modem to the harness with a zip tie • When mounting the Modem, make sure you still have access to the fuse panel Version 4.10.2 Proprietary and Confidential 2015-2018 Ford Transit...
  • Page 10 2015-2018 Ford Transit Install Guide Modem & PDC Mounting (Continued): • Notice the Modem mounted with access to all fuses Version 4.10.2 Proprietary and Confidential 2015-2018 Ford Transit...

  • Page 11: Step 6 - Wire Routing

    2015-2018 Ford Transit Install Guide IT’S IMPORTANT TO NEATLY ZIP TIE WIRES TO A FACTORY BRACKET OR HARNESS TO PREVENT FROM FALLING. KEEP AWAY FROM THE STEERING FUNCTIONS AND ANY MOVING PARTS Step 6 – Wire Routing: • Bundle up the extra wire and zip tie it to the factory bracket or harness in the top of the dash cavity •...
  • Page 12 2015-2018 Ford Transit Install Guide Step 7 - Recorder Mounting: Large truck with split window Factory Sensor under Mirror Small Passenger Vehicle Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A). If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a distraction to the driver (Photo B).
  • Page 13 2015-2018 Ford Transit Install Guide To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 4.10.2 Proprietary and Confidential 2015-2018 Ford Transit...
