Rosco Dual-Vision XC4 Installation Manual

For ford econoline
Hide thumbs Also See for Dual-Vision XC4:

Advertisement

Quick Links

Download this manual
1985-2003 Ford Econoline
This guide will show the proper way to install a Dual-Vision XC4 Camera in a 1985-2003 Ford Econoline.
Please review the Installation Guidelines for grounding and making connections prior to installing. In this
guide you will find dash removal, wire locations, & mounting locations.
Use Tool1130 For Recorder angle adjusting (Optional)
THIS GUIDE WILL WORK WITH DIESEL & STANDARD VEHICLES
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
accidental shorts or blown fuses
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
vehicle has any damage
th,
UPDATED October 15
2018
***NEW PART***
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Techsupport@Roscovision.com
Blue – Extra Installation Parts Needed
Gray – Installation Warning
Purple – New Installation
Red – Urgent Warning
Version 5.10.2
Proprietary and Confidential
1985-2003 Ford Econoline

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 1985-2003 Ford Econoline This guide will show the proper way to install a Dual-Vision XC4 Camera in a 1985-2003 Ford Econoline. Please review the Installation Guidelines for grounding and making connections prior to installing. In this guide you will find dash removal, wire locations, & mounting locations.
  • Page 2 1985-2003 Ford Econoline Before starting your install, its best to prep the windshield for recorder mounting Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield IMPORTANT: VHB Tape should only be applied when windshield temperature is within 50°F-...

  • Page 3: Step 1 - Dash Removal

    1985-2003 Ford Econoline Step 1 - Dash Removal: • Starting from the top pry the lower dash panel and pull down to remove Version 5.10.2 Proprietary and Confidential 1985-2003 Ford Econoline...
  • Page 4 1985-2003 Ford Econoline Dash Removal Continued: • Remove the Three 8MM bolts on both sides of the metal support brace (6 in total) • This will give you access to power connections & mounting location. Version 5.10.2 Proprietary and Confidential 1985-2003 Ford Econoline...

  • Page 5: Step 2 - Power Connections

    1985-2003 Ford Econoline Step 2 - Power Connections: • Locate the green and tan ignition plug attached to the steering column • Connect the RED Constant wire to the vehicles Yellow wire • Connect the YELLOW Ignition wire to the vehicles Red/Green wire •...

  • Page 6: Step 3 - Antenna Mounting

    1985-2003 Ford Econoline Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 7 1985-2003 Ford Econoline Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) • Make these connections prior to mounting the modem &...
  • Page 8 1985-2003 Ford Econoline Step 5 - PDC & Modem Mounting Locations: • The Modem can be attached to the factory harness on the left side of the cavity behind the dash • Secure the modem with a zip tie Version 5.10.2 Proprietary and Confidential 1985-2003 Ford Econoline...
  • Page 9 1985-2003 Ford Econoline PDC & Modem Mounting Location Continued: • Mount the PDC with a self-taping screw on the support located on the right side of the dash cavity Version 5.10.2 Proprietary and Confidential 1985-2003 Ford Econoline...
  • Page 10 1985-2003 Ford Econoline IT’S IMPORTANT TO NEATLY ZIP TIE WIRES TO A FACTORY BRACKET OR HARNESS TO PREVENT FROM FALLING. KEEP AWAY FROM THE STEERING FUNCTIONS AND ANY MOVING PARTS PLEASE READ THE RECORDER MOUNTING & VHB TAPE INSTALLATION GUIDELINE BEFORE PROCEDING TO THE NEXT STEP.
  • Page 11 1985-2003 Ford Econoline Step 6 - Camera Mounting and wire Routing: Large truck with split window Small Passenger Vehicle Factory Sensor under Mirror Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A). If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a distraction to the driver (Photo B).
  • Page 12 1985-2003 Ford Econoline To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 5.10.2 Proprietary and Confidential 1985-2003 Ford Econoline...
