Rosco Dual-Vision XC4 Installation Manual

For 7 dodge durango
Hide thumbs Also See for Dual-Vision XC4:

Advertisement

Quick Links

Download this manual
2004-2007 Dodge Durango Installation Guide
This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2004-2007 Dodge Durango.
Please review the Installation Guidelines for grounding and making connections prior to installing. In this
guide you will find dash removal, wire locations, & mounting locations.
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
vehicle has any damage
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
accidental shorts or blown fuses
th,
UPDATED October 15
2018
***NEW PART***
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Techsupport@Roscovision.com
Blue – Extra Installation Parts Needed
Gray – Installation Warning
Purple – New Installation
Red – Urgent Warning
Before starting your install, its best to prep the windshield for recorder mounting
Version 4.10.2
Proprietary and Confidential
2004-2007 Dodge Durango

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 2004-2007 Dodge Durango Installation Guide This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2004-2007 Dodge Durango. Please review the Installation Guidelines for grounding and making connections prior to installing. In this guide you will find dash removal, wire locations, & mounting locations.
  • Page 2 2004-2007 Dodge Durango Installation Guide Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield IMPORTANT: VHB Tape should only be applied when windshield temperature is within 50°F- 100°F (10°C-38°C) to allow proper curing of mounting adhesive pads.

  • Page 3: Step 1 - Dash Removal

    2004-2007 Dodge Durango Installation Guide Step 1 - Dash Removal: • Starting from the top and pry the lower dash panel. Pull down to remove (Photo A) • Remove the side panel with a panel tool (Photo B) Version 4.10.2 Proprietary and Confidential 2004-2007 Dodge Durango...

  • Page 4: Step 2 - Power Connections

    2004-2007 Dodge Durango Installation Guide Step 2 - Power Connections: • The Constant & Ignition wires are located at the steering column • Connect the RED CONSTANT WIRE to the vehices RED/BLUE wire • Conect the YELLOW IGNITION WIRE to the vehicles PINK/GREEN wire •...

  • Page 5: Step 3 - Antenna Mounting

    2004-2007 Dodge Durango Installation Guide Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 6 2004-2007 Dodge Durango Installation Guide Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) •...
  • Page 7 2004-2007 Dodge Durango Installation Guide Step 5 - PDC & Modem Mounting Location: • The Modem is located in the cavity behind the side panel • Secure the Modem with a zip tie around the two metal brackets (Arrow below) Version 4.10.2 Proprietary and Confidential 2004-2007 Dodge Durango...
  • Page 8 2004-2007 Dodge Durango Installation Guide PDC & Modem Mounting Locations (Continued): • The PDC is mounted behind the dash attached to the factory harness with a zip tie • Mount the PDC in the same direction as shown below. The skinny part can slide between the two brackets Version 4.10.2 Proprietary and Confidential...
  • Page 9 2004-2007 Dodge Durango Installation Guide PDC & Modem Mounting Location Continued: IT’S IMPORTANT TO NEATLY ZIP TIE WIRES TO A FACTORY BRACKET OR HARNESS TO PREVENT FROM FALLING. KEEP AWAY FROM THE STEERING FUNCTIONS AND ANY MOVING PARTS PLEASE READ THE RECORDER MOUNTING & VHB TAPE INSTALLATION GUIDELINE BEFORE PROCEDING TO THE NEXT STEP Version 4.10.2 Proprietary and Confidential...
  • Page 10 2004-2007 Dodge Durango Installation Guide Step 6 - Camera Mounting and wire Routing: Large truck with split window Factory Sensor under Mirror Small Passenger Vehicle Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A). If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a distraction to the driver (Photo B).
  • Page 11 2004-2007 Dodge Durango Installation Guide To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 4.10.2 Proprietary and Confidential 2004-2007 Dodge Durango...
