INTRODUCTION

PARTS IDENTIFICATION

Front

1 Shutter release button
2 Power button [ON/OFF]
3 Flash
4 Terminal cover
5 Self-timer lamp
6 Lens
7 [USB] port

Back

8 Viewfinder
9 Operation lamp
10 (PLAY mode)
11 (REC mode)
12 Zoom controller
13 Terminal cover
14 [DC IN 3V] terminal
15 Strap ring
16 Multi-controller [ ][
17 [DISP] button
18 [SET] button
19 [MENU] button
20 LCD Monitor
][ ][ ]
20
1
2
3
6
8
9
10
11
12
19
18
17 16
3
4
7
13
14
15
