  • Page 2: System Requirements Windows

    SYSTEM REQUIREMENTS WINDOWS • Windows®98/98 SE/Windows®2000 Prof./ Windows® Me / Windows®XP • 32 MB RAM • 110MB free memory capacity • VGA colour monitor • CD ROM drive • USB SYSTEM REQUIREMENTS IMac,iBook,G3 blue&white series,G4 series • MacOS 9.0~10.1.3 • 64 MB RAM or higher •...
  • Page 3 Thank you for purchasing the Concord Eye-Q-5330z. Please take the time to read through this instruction manual so you can enjoy all its features. This mark on your camera certifies that this camera meets the requirements of the EU (European Union) concerning interference causing equipment regulations.

  • Page 4: For Proper And Safe Use

    FOR PROPER AND SAFE USE Read and understand all warnings and cautions before using this product. This is a descriptive statement warning of the result if the instructions are ignored or not understood. Batteries may become hot or explode due to improper use. •...
  • Page 5 • Never charge alkaline betteries. • Do not use leaking batteries.If fluid from the batteries in your eyes,immediately rinse eyes with lots of fresh water and contact the doctor.If fluid from the batteries makes contact with your skin or clothing,please wash the area smoothly. •...
  • Page 6 The heat of the camera rises with extended periods of use. Use cautionsly when handling the camera or removing the batteries and compact flash card. • Do not leave the camera in places subject to extermely high temperatures,like a sealed vehicle,direct sunlight or other places of high temperature.

  • Page 7: Before You Begin

    Check the packing list before you begin. If some parts are missing, contact your camera dealer or call our customer service hotline listed on the warranty card. • Concord Eye-Q-5330z zoom camera (x 1) • AA-size Alkaline Batteries (x 4) •...

  • Page 8: Table Of Contents

    TABLE OF CONTENTS FOR PROPER AND SAFE USE ...4 BEFORE YOU BEGIN ....7 TABLE OF CONTENTS .
  • Page 9 IN THE AUTOFOCUS MODE ... . .38 WHEN THE SUBJECT IS NOT IN THE CENTER OF THE FRAME (Focus Lock Function) ....39 ADJUSTING THE FOCUS DISTANCE .
  • Page 10 PLAYBACK MODE SINGLE-FRAME PLAY ....80 THE PLAYBACK MODE DISPLAY ON THE LCD MONITOR .....81 THE IMAGE INFORMATION DISPLAY IN THE PLAYBACKMODE .
  • Page 11 SETUP THE SETUP MODE MENU DISPLAY ..115 THE SETUP MODE MENU DISPLAY ON THE LCD MONITOR ....115 THE SETUP MODE MENU ITEMS AND EACH SETTINGS .

  • Page 12: Names Of Parts

    NAMES OF PARTS CAMERA BODY_FRONT VIEW * Do not touch.
  • Page 13 CAMERA BODY_REAR VIEW...

  • Page 14: Inside The Terminal Cover

    INSIDE THE TERMINAL COVER USB connector Video-out terminal DC terminal BOTTOM OF BODY Battery-chamber door Tripod socket...

  • Page 15: Data Panel

    DATA PANEL The following diagram shows all items displayed to aid the explanation. Image-size indicators Number display of recordable remaining frame/ No-card indicator * Refer to the number of recordable remaining frame as a guide. The number changes depending on the scene or subject you record. Flash-mode indicators Battery-condition indicator Self-timer indicator...

  • Page 16: Viewfinder

    VIEWFINDER Focus Iamp Close-framing guide (green) Flash Iamp (red) Close-framing guide When you shoot a subject which is closer than 1m through the viewfinder, only the part under the close-framing guide is recorded. So, use the LCD monitor to check the image composition when you shoot a subject which is closer than 1m.
  • Page 17 Focus Lamp (Green) Lights. Blinks quickly (about 8 times in a second). Blinks slowly (about 2 times in a second). Focus Area (as a Guide) Flash Lamp (Red) Lights. Blinks quickly when the shutter-release button is pressed full-way down (about 8 times in a second). (When the flash function is cancelled) Blinks slowly (about 2 times in a second).

  • Page 18: Quick References

    QUICK REFERENCES GETTING STARTED 1 1 Insert the batteries (see page 25). 2 2 Insert the CF card (see page 29). Caution: We advised to use Sandisk or Hitachi CF card. TAKING PICTURES – See page 33 for details. 1 1 Rotate the function dial to 2 2 Slide the power switch to turn on the camera.
  • Page 19 3 3 Determine the image composition while looking into the LCD monitor or viewfinder. 4 4 Adjust the image range and size with the four-way keys • When the key is pressed, the image size becomes large. • When the key is pressed, the image range becomes wide.

  • Page 20: Monitoring The Captured Images

    MONITORING THE CAPTURED IMAGES – See page 82 for details. 1 1 Rotate the function dial to 2 2 Slide the power switch to turn on the camera. • The latest image (which was recorded last) is displayed on the LCD monitor. 3 3 When the next or previous one respectively.

  • Page 21: Deleting Images

    DELETING IMAGES – See page 92 for details. 1 1 Display the image to be deleted on the LCD monitor by per- forming from steps 1 1 to 3 3 of "MONITORING THE CAP- TURED IMAGES" described on the previous page. 2 2 Press the MENU button.
  • Page 22 • The image to be deleted is displayed on the LCD monitor and the display to conform whether you delete the image or not appears as shown in the figure. 5 5 Press the • The image displayed on the LCD monitor in step 1 is deleted. 6 6 To complete the operation of deleting an image, after con- firming that [NO] is highlighted in the display to confirm, press the ENTER button.

  • Page 23: Preparation

    PREPARATION...

  • Page 24: Attaching The Hand Strap

    ATTACHING THE HAND STRAP 1 1 Insert the smaller loop of the hand strap through the strap eyelet. 2 2 Insert the other end of the hand strap through the small loop.

  • Page 25: Inserting The Batteries

    INSERTING THE BATTERIES This camera uses four AA-size alkaline or Ni-MH batteries. * When using AA-size Ni-MH batteries, fully recharge them with a vendor-endorsed battery charger. 1 1 When replacing the batteries, slide the power switch to turn off the camera. •...
  • Page 26 4 4 Close the battery-chamber door in the direction of the arrow 1 and slide it until it clicks 2 . • After replacing the batteries, check that the built-in clock (date and time) works correctly (See page 121). If neither AC adapter nor batteries are used more than 5 minutes, the built-in clock may delay or be reset to the default setting.

  • Page 27: Checking The Battery Power

    CHECKING THE BATTERY POWER When the batteries are installed in the camera, the camera checks the battery power automatically and shows the result on the data panel. All indicators go out and after that, blinks for 5 seconds and then, all indicators go out again.

  • Page 28: Auto Power Off

    AUTO POWER OFF To save the battery power, This camera will turned off automatically if it is not operated more than 5 minutes. (Auto Power Off function) To operate the camera, slide the power switch to turn on the camera again. •...

  • Page 29: Inserting/Removing The Compact Flash(Cf) Card

    INSERTING/REMOVING THE COMPACT FLASH(CF) CARD Be sure to turn off the power of the camera when inserting or removing the CF card into or from the camera. Otherwise, the data in the card may be lost or the card may be damaged. If you insert or remove the CF card when the camera is turned on, re-format the CF card after trans- ferring the data from the card to your computer if the data is safe.

  • Page 30: Removing The Cf Card

    INSERTING/REMOVING THE COMPACT FLASH(CF) CARD 3 3 Fold the card-release lever down as shown in the figure. • Be sure to fold the lever. Otherwise, the card-slot door cannot be closed. 4 4 Close the card-slot door until it clicks. REMOVING THE CF CARD 1 1 Confirm that the power of the camera is turned off.
  • Page 31 INSERTING/REMOVING THE COMPACT FLASH(CF) CARD 3 3 Lift the card-release lever up as shown in the figure. 4 Push in the card-release lever straight. • As the CF card ejects slightly from the camera, pull out the card. • Be careful with the card because it may be hot. •...

  • Page 32: Taking Pictures

    TAKING PICTURES...

  • Page 33: Basic Recording Procedure

    BASIC RECORDING PROCEDURE 1 1 Rotate the function dial to 2 2 Slide the power switch to turn on the camera. • The power switch returns to the initial position. When the power switch on in the recording mode, the initial setup for LCD monitor is off, if you need turn on the LCD, please press 3 3 Determine the image composition while looking into LCD monitor or viewfinder.
  • Page 34 5 5 Press the shutter-release button half-way down. • The camera adjusts the focus automatically. When the subject is focused, the focus lamp (green) lights up. • When the focus lamp (green) blinks, follow the operation from step 3 again. •...

  • Page 35: The Recording Mode Display On The Lcd Monitor

    THE RECORDING MODE DISPLAY ON THE LCD MONITOR Each time the display button is pressed, the display on the LCD monitor changes in the following order. The LCD monitor is turned off Live view Live view (The camera settings are not displayed) (The camera settings are displayed)

  • Page 36: The Display Of The Camera Settings

    THE DISPLAY OF THE CAMERA SETTINGS (For details, see the pages in parentheses)

  • Page 37: Adjusting The Focus

    ADJUSTING THE FOCUS FOCUS LAMP When the shutter-release button is pressed halfway, this camera adjusts the focus automatically and the focus lamp (green) shows the focus status (when the focus mode is set to the autofocus mode.) Lights Blinks quickly (abort 8 times in a second) When the focus lamp (green) blinks, check the following points: •...

  • Page 38: In The Autofocus Mode

    THE SUBJECT THAT IS DIFFICULT TO FOCUS IN THE AUTOFOCUS MODE The autofocus mode uses the image contrast (the difference of light and dark parts) on the CCD (Charge Coupled Device) to focus on. Therefore, with the autofocus mode, the focus may not be adjusted correctly on the following subjects.

  • Page 39: When The Subject Is Not In The Center Of The Frame (Focus Lock Function)

    WHEN THE SUBJECT IS NOT IN THE CENTER OF THE FRAME (Focus Lock Function) When the subject is not in the center of the frame, the camera adjusts the focus on the background. In this case, take a picture with the focus lock function. 1 1 Aim the camera so that the subject is in the center of the frame and press the shutter-release button half-way down.

  • Page 40: Adjusting The Focus Distance

    ADJUSTING THE FOCUS DISTANCE Keep pressing key allows you to adjust the Focus Distance to the best situations. Auto focus The camera will automatically adjust the focus according to distance to subject. (No icon) The camera will adjust the focus to infinity.Flash was default to be disabled. Landscape The camera will focus closely to subject from 8 cm to 40cm.

  • Page 41: Close Up

    CLOSE UP The close up function allows you to take a picture close to the subject up to 8 cm filling the frame with the subject in about 6 cm x 4 cm. 1 1 Rotate the function dial to •...
  • Page 42 4 4 Press the shutter-release button half-way down. • If the focus lamp (green) blinks, check that the subject is within the distance from 8 cm to 40 cm (is not apart more than 40 cm from the camera). 5 5 Press the shutter-release button full–way down to take the picture.

  • Page 43: Adjusting The Focus Area

    ADJUSTING THE FOCUS AREA Adjust the focus area while looking into the LCD monitor. 1 Rotate the function dial to • The recording mode menu is displayed on the LCD monitor 2 Press the press the 3 Press the Central Spot key so that [FOCUSING] is highlighted and key.

  • Page 44: Flash

    FLASH With this camera, the following 5 flash modes are available. You can select them according to your purpose or condition. AUTOFLASH FILL-FLASH FLASH CANCEL AUTOFLASH WITH RED-EYE REDUCTION NIGHT MODE Flash Range The flash range has the limit. Take pictures by referring to the flash range indicated below The flash range:wide The flash fires automatically when the light level is low or the subject is backlit.

  • Page 45: Selecting The Flash Mode

    SELECTING THE FLASH MODE 1 1 Rotate the function dial to • The recording mode menu is displayed on the LCD monitor. 2 2 Press key to change the Flash mode as follows : AUTOFLASH FILL-FLASH FLASH-CANCEL AUTOFLASH WITH RED-EYE REDUCTION NIGHT MODE...

  • Page 46: Flash Lamp

    *The camera usually shows the icon shot with FLASH-CANCEL mode • The selected flash mode is displayed with the icon shown on the previous page on the upper right side of the LCD monitor (see page 36). • The flash mode returns to "AUTOFLASH WITH RED-EYE REDUCTION" when the camera is turned off and on again.

  • Page 47: Advanced Operations

    ADVANCED OPERATIONS...

  • Page 48: P/A/S/M Exposure

    P/A/S/M EXPOSURE EXPOSURE MODES These 4 exposure modes allow extensive control over general photo taking.Programmed Auto P gives carefree operation;Aperture Priority A and Shutter Priority S allow users to maximize exposures in different case;Manual Exposure M provides complete freedom in controlling. Options Purpose Programmed auto The camera will automatically set the...
  • Page 49 In P/A/S/M menu: (Rotate the function dial to 1 Press the lighted and press 2 Select the desired mode by pressing key to confirm the settings. In A/S/M mode: Programmed Auto 1. Press Aperture Priority speed. Shutter Priority Manual Exposure Aperture Priority You can adjust both aperture and shutter speed in M mode.

  • Page 50: Digital Zoom

    DIGITAL ZOOM The digital zoom function can increase the maximum magnification (about 24 mm) of the optical zoom lens (102 mm in the 34 mm film format equivalent) up to 2 times. 1 1 In the recording mode, press the mode so that the image is zoomed to the maximum.
  • Page 51 3 3 While looking into the LCD monitor, determine the image composition so that the desired image is positioned within the range of the indicator. 4 4 Press the shutter-release button half-way down. 5 5 Press the shutter-release button full–way down to take a picture.

  • Page 52: Continuous Shooting

    CONTINUOUS SHOOTING This digital camera will continuously take pictures while the shutter-release button is held down. The maximum number of images that can be captured at a time in follows(with 32MB CF card): Image quality FINE (Fine) STD. (Standard) ECON. (Economy) * See page 68 for the image quality and page 71 for the image size.
  • Page 53 Single shot Continuous shot Continuous with AF Self-timer • When taking a continuous shot,The flash mode is set to "FLASH CANCEL" automatically. • When the single shot or the self-timer shot is selected, the flash mode returns to "AUTOFLASH WITH RED-EYE REDUCTION".

  • Page 54: Self-Timer

    SELF-TIMER The picture is taken about 10 seconds after the shutter-release button is pressed. 1 1 After fixing the camera on the tripod, rotate the function dial 2 2 Press ENTER button to still change the [DRIVE MODE] to SELF-TIMER 3 3 Determine the image composition while looking into LCD monitor or viewfinder and adjust the image range and size with the...
  • Page 55 4 4 Press the shutter-release button half-way down. 5 5 Press the shutter-release button full-way down to start timer. • While the self-timer is functioning, the self-timer lamp in the front of the cam- era blinks. As the time to take the picture is closer, the lamp blinks faster. And just before taking the picture, the lamp lights up to show the time to take a shot.

  • Page 56: Iso Setting

    ISO SETTING Select the camera's sensitivity to light. ISO is the standard used to indicate film sensitivity.Raising the ISO sensivity will mean that the cam- era needs less light in order to take an image.However,the higher the ISO value is,the grainier the image will be.

  • Page 57: Exposure Compensation

    EXPOSURE COMPENSATION This function makes the image brighter or darker by adjusting the exposure compensation value for CCD. The bigger the exposure compensation value is, the brighter the image is and the smaller the exposure compensation value is, the darker the image is. 1 1 Rotate the function dial to •...
  • Page 58 4 4 Press the sation value and press • The exposure compensation value from +2.0 to –2.0 can be specified by 1/3 step. 5 5 Press the MENU button. • The exposure compensation value is specified and displayed on the upper right side of the LCD monitor (see page 36).

  • Page 59: Movie Clip Shot

    MOVIE CLIP SHOT Movie clip shot The extra function allow users to take Motion Pictures in the camera with 15fps. 1 Rotate the function dial to MOVIE CLIP mode • The LCD monitor will be displayed as shown. 2 Press the shutter button once and movie clips are recorded for as long as the available recording time allows.

  • Page 60: Movie Clip Playback

    MOVIE CLIP PLAYBACK 1 Rotate the function dial to • The image files (including movie clips) will be shown on LCD monitor. 2 Press • The movie clip shows the icon 3 Press MOVIE CLIP SETTING 1 Rotate the function dial to •...

  • Page 61: Voice Recording

    VOICE RECORDING RECORDING VOICES FOR MEMORIAL PICTURES The function allows user to record some voices in any picture which you like. 1 1 Rotate the function dial to • The latest image is displayed on LCD monitor. 2 2 Press 3 3 Press displayed.

  • Page 62: Voice Playback

    VOICE PLAYBACK 1 1 Rotate the function dial to • The last shot is displayed on LCD monitor. 2 2 Press • The icon 3 Press • Press once: PLAY Press once more: PAUSE key to select the image file with voice. of the image is displayed on LCD monitor.

  • Page 63: Specifying The Recording Mode

    SPECIFYING THE RECORDING MODE...

  • Page 64: The Recording Mode Menu Display (Lcd Monitor)

    SPECIFYING THE RECORDING MODE THE RECORDING MODE MENU DISPLAY (LCD Monitor) THE RECORDING MODE MENU ITEMS FLASH (For the Flash mode, see page 44) FOCUSING (For the Focus mode,see page 37) (For the ISO setting,see page 56) (Auto-flash) (Fill-flash) (Flash cancel) (Auto-flash with red-eye reduction) (Night mode) Central...

  • Page 65: Drive Mode

    DRIVE MODE (For the Drive mode, see page 52) IMAZE SIZE (For the Image size ,see page 71) QUALITY (For the Image quality, see page 68) WHITE BALANCE (For the White Balance, see page 73) (Single shot)* (Continuous shot ) (Continuous with AF) (Self-timer shot) FULL (2560X1920)
  • Page 66 EXPOSURE (For the Exposure com- AREA pensation see page 57) SHARPNESS (For the Sharpness, see page 75) (For the LCD, see page 99) DEFAULT (For the Default, see page 77) FULL CENTRAL SPOT HARD NORMAL SOFT +2.0 +1.7 +1.3 +1.0 +0.7 +0.3 -0.3...
  • Page 67 MOVIE CLIP SHOT(For the MOVIE CLIP MODE,see page 59) REC.TIME VOICE * The settings indicated with mark are resumed when the power of the camera is turned off and on, or when the batteries are removed and inserted, For "QUALITY" and "IMAGE SIZE", the camera memorizes the last setting before the power of the camera is turned off or before the batteries are removed.

  • Page 68: Specifying The Image Quality Mode

    SPECIFYING THE IMAGE QUALITY MODE This camera has 3 image quality modes; " The image quality is related to the compression ratio of the image. The compression rate is higher in the order of " " " image quality is. When you want high quality images, select " is low, the number of the images to be recorded in the CF card is less than that in the "...
  • Page 69 1 1 Rotate the function dial to • The recording mode menu is displayed on the LCD monitor. 2 2 Press the key so that [QUALITY] is highlighted and press the key. 3 Press the key so that the desired image quality mode is highlighted and press •...
  • Page 70 5 5 Press the MENU button. • The selected image quality mode is specified and displayed on the upper left side of the LCD monitor (see page 36). * It does not matter if there are images recorded in different image quality modes in one CF card. * The setting of the image quality mode is stored in the camera’s memory even after the camera is turned off.

  • Page 71: Specifying The Image Size Mode

    SPECIFYING THE IMAGE SIZE MODE Before taking pictures, select the image size. Changing the image size affects the number of the image which can be recorded in the CF card. The " FULL " " LARGE " " HALF " or VGA size can be selected.
  • Page 72 3 3 Press the is highlighted and press the • The image size mode changes in the following order. FULL (2560X1920) LARGE (1600X1200) 5 Press the MENU button. • The selected image size mode is specified and displayed under the image quality on the upper left side of the LCD monitor (see page 36).

  • Page 73: Specifying The White Balance Mode

    SPECIFYING THE WHITE BALANCE MODE This camera has 6 white balance modes. Auto white balance AUTO It adjusts white balance according to light source incident on the CCD in normally. Daylight mode Select this mode when taking the picture of the subject illuminated by a sunlight. Light bulb mode Select this mode when taking the picture of the subject illuminated by an incandescent light or tungsten light.
  • Page 74 3 3 Press the mode is highlighted, press • The white balance mode changes in the following order. 4 4 Press the MENU button. • The selected white balance mode is specified and the icon of the selected white balance mode is displayed on the left side of the flash mode on the upper right side of the LCD monitor (see page 36).

  • Page 75: Specifying The Sharpness Mode

    SPECIFYING THE SHARPNESS MODE This camera has three sharpness modes as described below. HARD This enhances the sharpness of image. NORMAL No effect of sharpness. SOFT This reduces the sharpness of image and makes an image soft. 1 Rotate the function dial to •...
  • Page 76 3 3 Press the highlighted. • The sharpness mode changes in the following order. 4 4 Press the 5 5 Press the MENU button. • The selected sharpness mode is specified and there would be no icon displayed on the LCD monitor. However, even if "HARD" or "SOFT" is selected.

  • Page 77: Reseting To The Recording Mode Default Settings

    RESETING TO THE RECORDING MODE DEFAULT SETTINGS This allows you reset this camera’s RECORDING MODE to the default at a time. The camera settings Flash Focus-mode Focus-Area Drive Mode Image size Quality White Balance Exposure-EV Exposure-Area Sharpness The default settings Autoflash with red-eye reduction Auto Central region...
  • Page 78 1 Press the key so that [DEFAULT] is highlighted and press key. 2 Press the key so that [YES] is highlighted and press key. • The camera settings are reset to the default. •The LCD monitor display return to the recording mode menu.

  • Page 79: Playback Mode

    PLAYBACK MODE...

  • Page 80: Single-Frame Play

    SINGLE-FRAME PLAY The images recorded in the CF card can be displayed by one frame on the LCD monitor. 1 1 Rotate the function dial to • The function dial can be rotated even when the camera is turned on. 2 2 When the camera is not turned on, slide the power switch to turn on the camera.

  • Page 81: The Playback Mode Display On The Lcd Monitor

    THE PLAYBACK MODE DISPLAY ON THE LCD MONITOR THE PLAYBACK MODE DISPLAY ON THE LCD MONITOR Each time the display button is pressed, the display on the LCD monitor changes in the following order. (9 frames) Single-frame play (with the image information) Index Single-frame play (with no image information)

  • Page 82: The Image Information Display In The Playbackmode

    THE IMAGE INFORMATION DISPLAY IN THE PLABACK MODE Recorded date and time of the image Frame number of the image/Total frame number recorded in the CF card When the camera enters the index play mode, the frame number of the image displayed last in the sin- gle-frame play mode is highlighted.

  • Page 83: Index Play

    INDEX PLAY This mode allows you to display 9 frames at a time on the LCD monitor. It is convenient when you search the desired image quickly. 1 1 When the camera is set to the single-frame play mode, press the display button •...
  • Page 84 2 2 Press • When the number of the image is highlighted. When the ing imaged is selected and the frame of the image is highlighted. • When the ninth frame is selected (when the number 9 is highlighted) and the •...

  • Page 85: Zoom Play

    ZOOM PLAY This mode allows you to increase the magnification of image around the center 2.0 times and display it on the LCD monitor. It is convenient when checking the details of the image. 1 1 Rotate the function dial to •...
  • Page 86 4 4 Press the image. • The image moves slightly in the direction of the key you press. The image keeps moving while the key is held and pressed. 5 5 To cancel the zoom play mode, press the MENU button. •...

  • Page 87: Slide Show

    SLIDE SHOW The images can be played back continuously on the LCD monitor like an automatic slide show. TO START THE SLIDE SHOW 1 1 Rotate the function dial to • The play back mode menu is displayed on the LCD monitor. 2 2 Press the and press 3 3 Press the...

  • Page 88: To Stop The Slide Show

    TO STOP THE SLIDE SHOW Press one of the following buttons or keys while the slide show is performed. The slide show stops temporarily. • the • MENU button • When the ENTER button is pressed while the slide show stops temporarily, the slide show stop.

  • Page 89: The Setting In The Slide Show Mode Menu

    THE SETTING IN THE SLIDE SHOW MODE MENU 1 1 Rotate the function dial to and press the MENU button. 2 2 Press the key so that [SLIDE SHOW] is highlighted and press key. 3 3 Press the key so that [TIME] is highlighted, and press key.
  • Page 90 5 5 Press the 6 6 Press the and press 7 7 Press the lighted and press • The direction changes in the following order. 8 8 Press the slide show. key to finish the setting. key so that [DIRECTION] is highlighted key.

  • Page 91: Deleting Images

    DELETING IMAGES...

  • Page 92: Deleting Selected Image

    DELETING SELECTED IMAGES The images recorded in the CF card can be deleted by an image while checking them displayed on the LCD monitor. CAUTION The deleted image cannot be recovered, BE CAREFUL when deleting an image. 1 Rotate the function dial to •...
  • Page 93 4 4 Press the MENU button. • The playback mode menu is displayed on the LCD monitor 5 5 Press the key so that [DELETE] is highlighted, press key. 6 6 Press the key so that [SELECT IMAGE] is highlighted, press the key.
  • Page 94 7 Press the DISPLAY button delete. • After pressing the be delete. 8 Press the ENTER button so that [YES] is highlighted, and press • "Delete selected image?" is displayed on the lower of the monitor. 9 9 To complete the operation of deleting an image, after con- firming that [NO] is highlighted in the display to confirm, press the •...

  • Page 95: Deleting All Images

    DELETING ALL IMAGES All images recorded in this folder can be deleted. CAUTION The deleted image cannot be recovered, be careful when deleting all images. 1 1 Rotate the function dial to • The function dial can be rotated even when the camera is turned on. 2 2 When the camera is not turned on, slide the power switch to turn on the camera.
  • Page 96 4 4 After confirming that [DELETE] is highlighted, press the key. 5 5 Press the press the • The display to confirm whether you delete all images or not appears as shown in the figure. • Only the images captured with this camera can be all deleted. Even if you insert the CF card in which the images captured with other camera is record- ed, the images cannot be deleted.

  • Page 97: Deleting Folders

    DELETING FOLDERS Delete the folder and all images in the folder CAUTION The deleted folder cannot be recovered, be careful when deleting any folder. 1 1 Rotate the function dial to • The function dial can be rotated even when the camera is turned on. 2 2 When the camera is not turned on, slide the power switch to turn on the camera.
  • Page 98 4 4 After confirming that [DELETE] is highlighted, press the key. 5 5 Press the 6 6 Press want to delete, press 7 7 Press finish the Deleting. • All images in the folder and the folder are deleted. • While all images are deleted, the focus lamp (green) blinks slowly (about two times a second).

  • Page 99: Adjusting The Brightness Of The Lcd Monitor

    ADJUSTING THE BRIGHTNESS OF THE LCD MONITOR This allows you to adjust the brightness of the LCD monitor according to the angle at which you watch it or the brightness around the monitor so that the display on the LCD monitor can be seen clearly. 1 1 Rotate the function dial to 2 2 After confirming that [LCD] is highlighted, press the •...

  • Page 100: Specifying The Playback Mode

    SPECIFYING THE PLAYBACK MODE...

  • Page 101: The Playback Mode Menu

    THE PLAYBACK MODE MENU THE PLAYBACK MODE MENU (LCD Monitor) THE PLAYBACK MODE MENU ITEMS AND EACH SETTINGS DELETE (For deleting images see page 92) ZOOM (For the zoom play mode, see page 85) SLIDE SHOW (For the slide show mode,see page 87) SELECT IMAGE DELETE ALL IMAGES...

  • Page 102: Lcd Bright

    PRINT (For specifying the print settings with the DPOF, see page103) FOLDER (see page 110) LCD BRIGHT (For adjusting the brightness of the LCD monitor, see page 99) * For "DELETE" (deleting images), see page 92. For "ZOOM" (zoom play), see page 85. For "SLIDE SHOW" (auto play), see page 87 Only the 2 items of "PRINT"...

  • Page 103: Specifying The Print Settings With The Dpof

    * The DPOF is jointly developed by Eastman Kodak Company, Canon Inc., Fuji Photo Film co., Ltd., and Matsushita Electric Industrial Co., Led. for direct printing from digital camera. SPECIFYING THE IMAGE AND THE NUMBER TO BE PRINTED 1 1 Rotate the function dial to and press the MENU button.
  • Page 104 SPECIFYING THE IMAGE AND THE NUMBER TO BE PRINT 3 3 Press the press 4 Press • When the image to be printed is selected, the number to be printed is high- lighted. • The sixth frame is selected and the frames are diaplayed.
  • Page 105 5 5 Press the key to select the number to be printed. • When the key is pressed, the number becomes large. When the key is pressed, the number becomes small. 6 6 Repeat step 4 4 and 5 5 to specify the number to be printed for all images.

  • Page 106: Specifying The Index Print Settings

    SPECIFYING THE INDEX PRINT SETTING This setting allows you to print all images recorded in the CF card on one sheet as an index print. The illustration of index print as an image. 1 Rotate the function dial to • The playback mode menu is displayed on the LCD monitor. 2 Press the press 3 Press the...
  • Page 107 • The DPOF file including data of the index print setting is recorded in the CF card. • After the file is recorded, the LCD monitor display returns to the playback mode menu. 4 Press the MENU button. • The LCD monitor display returns to the playback mode.

  • Page 108: To Cancel The Print Settings With The Dpof

    TO CANCEL THE PRINT SETTINGS WITH THE DPOF All Print settings with the DPOF described on page 103 can be cancelled. The index print setting (see page 106) is also cancelled. 1 1 Rotate the function dial to • The playback mode menu is displayed on the LCD monitor. 2 2 Press the press 3 3 Press the...

  • Page 109: Folder Name

    FOLDER NAME The folder in the CF card is conformed with DCF (Design rule for Camera File system) format. When taking a picture with this camera, the "Dcim" folder is made in the directory of the CF card and the "CD5330" folder is made in the "Dcim" folder. The first captured image is recorded with the file name of "SIMG001.jpg"...

  • Page 110: Selected An Folder

    SELECTED A FOLDER Even if other digital camera supporting the DCF format is used to record the captured images in the CF card, you can insert the CF card into this camera and play back the images by selecting the partic- ular folder name of other digital camera in the playback mode menu.

  • Page 111: Give Folder A New Name

    GIVE THE FOLDER A NEW NAME You could give the folder a new name in the FOLDER-NEW mode, determine the last 5 character arbitrary. 1 Rotate the funtion dial to •The playback mode menu is displayed on the LCD monitor. 2 Press the press 3 Press the...
  • Page 112 4 Press •If you won't give a new name, press the menu button back to playback menu. 5 Press the image to be played back is recorded is highlighted and press the ENTER button. • When only "CD5330" folder exists, the folder name does not change even key select the character you like and press key to determine.

  • Page 113: On Dcf (Design Rule For Camera File System) Format

    Through this format, the image files can be used between the digital equipment conformed to DCF. The following operation can be available between the digital equipment conformed to DCF: • The images captured with your digital camera can be played back on the LCD monitor of other digital camera.

  • Page 114: Setup

    SETUP...

  • Page 115: The Setup Mode Menu Display

    THE SETUP MODE MENU DISPLAY THE SETUP MODE MENU DISPLAY ON THE LCD MONITOR FORMAT (For formatting the CF card, see page 119) POWER SAVE (For the time for the auto power off function, see page 117) 1 min. (1 minute) 3 min.

  • Page 116: Video Out

    DATE/TIME (For setting or correcting the date and time, see page 121) BEEP (For turning on or off the beep, see page 123) VIDEO OUT (For switching the video signal from the video-out terminal, see page 125) LANGUAGE (For switching the language displayed on the LCD monitor, see page 127) DEFAULT (For resetting the camera, see page 128) DATE...

  • Page 117: Specifying The Time For The Auto Power Off Function

    SPECIFYING THE TIME FOR THE AUTO POWER OFF FUNCTION To save the battery power, this camera will be turned off automatically if it is not operated more than 5 minutes. (Auto Power Off function) The time for the auto power off function is set to 5 minutes unless you change the setting after you purchase this camera.
  • Page 118 4 4 Press the auto power off function is highlighted. • The time for the auto power off function changes in the following order. 5 5 Press the setting. ´Only when using the batteries, the time for the auto power off function can be specified. When using the AC adapter (sold separately), the time for the auto power off function is fixed in 30 minutes and cannot be changed.

  • Page 119: Formatting The Cfcard

    FORMATING THE CF CARD This allows user to format the CF card. CAUTION As all the images recorded in the CF card are deleted and cannot be recovered, be careful when formatting the CF card. 1 1 Rotate the function dial to "SETUP" and slide the power switch to turn on the camera.
  • Page 120 4 4 Press the key so that [YES] is highlighted and press the Key to finish the setting. • The format of the CF card starts. • After formatting the CF card, the LCD monitor returns to the setup mode menu display.

  • Page 121: Setting The Date / Time

    SETTING THE DATE / TIME When taking a picture, the date and time are recorded as the part of the image information. If the built-in clock of this camera is not set correctly, the wrong date and time ate recorded. Set the date and time correctly by performing the procedure below.
  • Page 122 4 4 Press the press • When you press and hold the fastbackward. 5 5 Press the and press • The display to set the date and time appears as shown in the figure. 6 6 Press the press the 7 7 Press the press the •...

  • Page 123: Setting The Beep Sound

    SETTING THE BEEP SOUND The beep sounds each time you operate this camera with the buttons or function dial and you can turn off or on the beep. The beep is turned on unless you change the setting after you purchase this camera.
  • Page 124 3 3 Select [ON] or [OFF] with the key. • The setting of the beep changes in the following order. ON (The beep sounds.) OFF (The beep does not sound.) 4 4 Press the key to finish the setting . •...

  • Page 125: Switching The Video Signal From The Video Output Terminal

    SWITCHING THE VIDEO SIGNAL FROM THE VIDEO OUTPUT TERMINAL As this camera has the video-out terminal, you can watch the captured images on TV by connecting this camera to your TV with the supplied video cable. The video output signal can be switched between NTSC and PAL. What is an NTSC system and a PAL system? Both are the color television broadcast system.
  • Page 126 3 3 Select [PAL] or [NTSC] with the • The setting of the beep changes in the following order. 4 4 Press the • The video signal system output from the video-out terminal is switched to the selected one. NTSC key to finish the setting.

  • Page 127: Switching The Language Displayed On The Lcd Monitor

    SWITCHING THE LANGUAGE DISPLAYED ON THE LCD MONITOR The language displayed on the LCD monitor can be switched to English. 1 1 Rotate the function dial to "SETUP" and slide the power switch to turn on the camera. • The setup mode menu is displayed on the LCD monitor as shown in the fig- ure.

  • Page 128: Resetting To The Default Settings

    RESETTING TO THE DEFAULT SETTINGS This allows you reset all this camera's PLAYBACK MODE, SETUP MODE, PC MODE to the default at a time. The camera playback settings Delete (see page 92) Slide show-Time (see page 89) Slide show-Direction (see page 87) Print(see page 103) Folders(see page 109) LCD(see page 99)
  • Page 129 1 Rotate the function dial to "SETUP" and slide the power switch to turn on the camera. • The setup mode menu is displayed on the LCD monitor as shown in the figure. 2 2 Press the key so that [DEFAULT] is highlighted and press the key.

  • Page 130: Connecting To The Personal Com

    CONNECTING TO THE PERSONAL COMPUTER...

  • Page 131: Installation Of The Driver Software

    INSTALLATION OF THE DRIVER AND APPLICATION SOFTWARE INSTALLATION OF THE DRIVER SOFTWARE The following operation is required for Windows®98 . ATTENTION WINDOWS 98 USERS: Please follow steps 1-10. ATTENTION WINDOWS 2000, ME, XP USERS: Please follow steps 6-10 after inserting the CD-ROM in the CD- ROM drive in your computer.
  • Page 132 INSTALLATION OF THE DRIVER AND APPLICATION SOFTWARE 3. Press "Next". . 4. Starting install driver. 5. Press "Finish " to complete installation.
  • Page 133 6. Press "Yes" to install DirectX 8.1. Important: DirectX 8.1 enables the movie playback applications on your computer to play movie clips that are captured with the Concord Eye-Q 5330z. (e.g. Windows Media Player) 7. Press "Yes". 8. Starting install DirectX 8.1.
  • Page 134 INSTALLATION OF THE DRIVER AND APPLICATION SOFTWARE 9. Press "OK" to complete installation. 10. Restart your computer.
  • Page 135 INSTALLATION PHOTOIMPRESSION For all Windows users. 1. Insert installation CD-ROM. 2. Press "Application" to install ArcSoft PhotoImpression. 3. Press "Next" to continue install PhotoImpression. 4. Press "Next".
  • Page 136 INSTALLATION PHOTOIMPRESSION 5. Press "Next". 6. Press "Next". 7. Press "Next".
  • Page 137 INSTALLATION PHOTOIMPRESSION 8. Starting set up. 9. Press "Finish" to complete installation.
  • Page 138 INSTALLATION VIDEOIMPRESSION1.6 1. Press "Application" to install ArcSoft VideoImpression. 2. Select language that you want and press "sure" 3. Preparing set up. 4. Press "Next".
  • Page 139 INSTALLATION VIDEOIMPRESSION1.6 5. Press "Yes". 6. Press "Next" to choose folder which you will save. 7. Press "Next".
  • Page 140 INSTALLATION VIDEOIMPRESSION1.6 8. Press "Next". 9. Starting install VideoImpression1.6. 10. Press "Finish" to complete installation.

  • Page 141: For Macintosh

    For Apple Macintosh (OS9, OS10) INSTALLATION DRIVER Do not need to install driver. INSTALLATION PHOTOIMPRESSION 1. Insert installation CD-ROM. 2. Click "ARCSOFT" to install PhotoImpression. 3. Click "PhotoImpression3" to set up software .
  • Page 142 For Apple Macintosh (OS9, OS10) 4. Click language that you want. 5. It will show below screen and click "PhotoImpression Installer". 6. Press "Accept".
  • Page 143 For Apple Macintosh (OS9, OS10) 7. Press "Install" to start installation.
  • Page 144 INSTALLATION VIDEOIMPRESSION1.6 1. Click "Video Impression1.6" to set up software. 2. Select language that you want. 3. It will show the below screen and click "VideoImpression1.6 Installer".
  • Page 145 INSTALLATION VIDEOIMPRESSION1.6 4. Press "Accept". 5. Click "Install" to start installation.

  • Page 146: Cautions When Connecting To The Personal Computer

    CAUTIONS WHEN CONNECTING TO THE PERSONAL COMPUTER • While this camera is connected to the computer or transferring the image data between this camera and the computer, do not perform the following operations. Otherwise, the error may occur, the camera and the computer may not function correctly, or the image data recorded in the CF card may be erased or damaged.
  • Page 147 CAUTIONS WHEN CONNECTING TO THE PERSONAL COMPUTER • When connecting the camera to the computer and transferring the image data between them, be sure to check that the battery capacity is full. If the battery power is low, the power of the camera may be turned off while transferring data.

  • Page 148: Videoimpression

    Requirements of PhotoImpression & VideoImpression To use the supplied image editing application PhotoImpression and VideoImpression, the following systems are required. For the IBM-PC/AT and the compatible unit Intel Pentium II processor of 233 MHz or more, or the computer equipped with the fully compatible processor. Windows®98/98SE/ME/2000/XP Windows®...

  • Page 149: Appendix

    APPENDIX...

  • Page 150: Watching The Captured Images On Tv

    WATCHING THE CAPTURED IMAGES ON TV WATCHING THE CAPTURED IMAGES ON TV By connecting this camera to your TV with the supplied video cable, you can watch the captured images on TV. 1.Confirm that the video out signal from the video-out terminal is set to NTSC or PAL according to the color system in your country.

  • Page 151: Troubleshooting

    TROUBLESHOOTING If you have any trouble with this camera, check the following items. Problem Check The focus cannot be Do you attempt to adjust the focus adjusted in the autofo- on the subject, which is difficult to cus mode The focus focus in the autofocus mode? lamp (green) blinks Do you attempt to take a picture...
  • Page 152 Problem Check The shutter- Is "CARD FULL" displayed on the release button LCD monitor? is not released. Is the power of the camera turned off? The live view Are the batteries exhausted? is not dis- played on the Are the batteries inserted with the LCD monitor.
  • Page 153 Problem Check Is the power of the camera turned off? Are the batteries exhausted? Are the batteries inserted with the The image correct polarity? cannot be played Is the CF card is inserted in the back on camera? ( Is "NO CARD" dis- the LCD played on the LCD monitor? ) monitor.
  • Page 154 Problem Check The zoom play Did you take a picture with the digi- cannot be per- tal zoom function? formed. The image is too Is the exposure compensation dark or bright. value specified? Even when the Has the lens comes out, indicator blinked (all the indicators the data panel is disappeared after 5 seconds ) ?

  • Page 155: Notes On The Handling

    NOTES ON THE HANDLING Batteries • Battery performance decreases with lower operating temperatures. In a cold place, we recommend you to prepare new batteries and keep the spare batteries in a warm place such as inside your coat. As the performance of Ni-MH battery less decreases, we recommend you to use the Ni-MH battery in a cold place.
  • Page 156 • Even if you insert the CF card including the data recorded with other digital camera supporting the DCF format, the DPOF data for the images captured with other digital camera ( the images in the...
  • Page 157 Operating Temperatures and Conditions • This camera has been designed for use in temperatures from 0ºC to 40ºC (32ºF to 104ºF). • Never leave the camera exposed to extreme high temperatures, such as in a car parked in the sun, or to extreme humidity.
  • Page 158 Others • Do not subject the camera to shock or impact. • Turn off the power of the camera when transporting. • This camera is neither waterproof nor splashproof. Inserting or removing batteries and the CF card, or operating the camera with wet hands may daage the camera.

  • Page 159: Care And Storage

    CARE AND STORAGE Cleaning • If the camera or the outside of the lens is dirty, gently wipe it with a soft, clean, dry cloth. If the cam- era or lens comes in contact with sand, gently blow away loose particles. Wiping may scratch the surface.

  • Page 160: Technical Details

    TECHNICAL DETAILS Camera Type Recording media exchangeable 3X zoom digital camera with LCD monitor Pickup elements: 1/1.8 inch-type inter line CCD, 5.13M pixels, with a base color filter Pickup system: single ISO sensitivity: AUTO ISO 100 200 400 Number of bit converted to A/D: 12 bit...
  • Page 161 Technical Suppor t Hot Line: Toll Free In the USA & Canada 1-866-522-6372 Toll Free In Europe UK: 0800-169-6482 BELGIUM: 0800-787-57 FRANCE: 0800-917-599 GERMANY: 0800-1800-563 SPAIN: 900-973-195 ITALY: 800-781-883 All Other Countries - Toll 31-53-482-9779...
  • Page 162 Storage capacity ( Using a 32 M B CF card ) : 2560x1920 size FINE approx. 13 images STD.(Standard) approx. 26 images ECOn.(Econmy) approx. 52 images The number of images to be recorded varies depending on the subject. Other: Delete function ( Single image. All images ) 1600x1200 size 1280x960 size approx.
  • Page 163 Autofocus System: AF system by CCD Focus locked when the shutter-release button is pressed halfway. Focus mode : One shot AF Manual Focus : Avaliable (operated with Auto Exposure (AE) Control Exposure mode : Programmed AE AE Locked when the shutter-release button is pressed halfway. Metering : Center weighted TTL metering Shutter:...
  • Page 164 Drive Mode Mode: Single shot, continuous shot(approx.1 frame / sec.), self-timer shot Self-timer: Approx. 10 second delayed release Built-in Flash Charge time: Approx. 8 second at fill flash Flash modes: Autoflash, Fill-flash,Flash cancel, Autoflash with red-eye reduction,Fill-flash with (Flash cancel in the close up mode),night mode. Flash intensity control: Adjusted automatically by an external light Interface Video output:...

Table of Contents

Save PDF
