OTHER RECORDING FUNCTIONS

Using the Macro Mode

Use the macro mode to take close-up shots. The following is the focus range in the Macro mode.
Range: Approximately 10cm to 70cm (3.9˝ to 27.6˝)
1. In the REC mode, press [
2. Record the image.
IMPORTANT!
• In the Macro mode, the optical zoom range is 1X to 1.2X.

Using the Infinity Mode

Use this mode when recording scenery and other far away images.
1. Press [ ] repeatedly until [
2. Record the image.

Using Manual Focus

With the Manual Focus mode selected, you can adjust the focus of an image manually. The following shows
focus ranges in the Macro mode for two optical zoom factors.
Optical Zoom Factor
1X
3X
Macro Mode
1. Press [ ] repeatedly until [MF] is displayed.
• At this point, a rectangle appears, which indicates that the
area within that boundary would be used for manual focus.
2. While watching the image on the monitor screen, press [
or [ ] repeatedly to focus.
[ ] Focuses out on the subject
[ ] Focuses in on the subject
3. Record the image.
] repeatedly until [ ] is displayed.
∞
] is displayed.
Approximate Focus Range
∞
10cm (3.9˝) to infinity (
∞
60cm (23.6˝) to infinity (
10cm (3.9") to 70cm (27.5")
19
)
)
]
Manual focus position
Boundary
