BASIC IMAGE RECORDING

BASIC IMAGE RECORDING
BASIC IMAGE RECORDING

RECORDING AN IMAGE

Your camera automatically adjusts shutter speed to suit the brightness of the subject.
1. Press the power button or the [
camera.
2. Aim the camera at the subject while looking through the
viewfinder to include the desired subject within the frame.
• The focusing range of the camera in the Auto Focus mode is
approximately 60cm (23.6˝) to infinity (∞)
3. Press the shutter release button half way down to focus on the
image.
• The camera's Auto Focus feature automatically focuses on
the image, one beep will sound when the camera has finished
metering, and the indicator beside the viewfinder will light
green.
• The shutter speed and aperture values appear on the LCD
monitor.
• If the subject is difficult to focus, the green LED blinks.
4. After ensuring that the image is focused properly, press the
shutter release button the rest of the way down to record.

USING ZOOM

Your camera is equipped with two types of zoom: optical zoom and
digital zoom.

Optical Zoom

The range of the optical zoom factor is shown below.
Factor Range: 1X to 3X
(1X to 1.2X in the Macro Mode)
1. In the REC mode, slide the zoom controller left or right to
change the zoom factor.
] (REC) button to turn ON the
13
IN
Focus frame
Shutter button
Green operation lamp
(Green LED)
Zoom Controller
