1.3 Oscilloscope Parameters
Channel
Real-time sampling rate
Time base range
Waveform Display Mode
Input Impedance
Probe Attenuation Coefficient
Trigger Type
Trigger Level Range
Storage Space
Band Width
Dual channel
Storage Depth
250MSa/s
Vertical Sensitivity
10ns/div - 10s/div
Vertical Resolution
YT/XY/scroll
Bandwidth limit
1MΩ
Input Coupling
1x/10x
Peak Voltage
Rising/Falling edge
8 cells
Trigger Mode
(positive/negative)
Measured Data
13M
50MHz
Up to 64kByte
10mv/div - 10v/div
8 bits
Support 20MHz limit
AC/DC
±400V
Auto/Normal/Single
Period, frequency, peak-
to-peak value, maximum
value, minimum value,
Average value, effective
value, amplitude, duty
cycle, pulse width
