Fnirsi 2C53P Manual page 26

②Channel 2 settings:Channel on/off, vertical voltage,
probe ratio, coupling type, and 20M bandwidth limit can be
set.
③System time base： Refers to a large grid in the horizontal
direction representing the length of time, consisting of
sampling Rate determines.
④Trigger settings： You can set the trigger mode, trigger
edge, and trigger channel.
⑤Function signal generator indication：
the function signal generator is on, grey means it is not on
⑥Run/Pause： Click this button to switch between running
and pausing.
⑦Power indicator： Indicates the system power.
1.2 Oscilloscope Menu Section
Save
Save
Measure
Measurement
Highlight means
Operation
Cursor
Afterglow
Calculation
Cursor Afterglow
⑧Channel 1 Waveform：
captured by channel 1.
⑨Trigger X position indicator arrow：
as the trigger point
⑩Channel 2 Waveform：
by channel 2
⑪Trigger voltage
threshold
⑫Cursor operations
⑬Home touch button
⑭Run/Stop button
⑮Auto measure button
⑯Menu button
X-Y Picture
X-Y
Correction
Correction
The waveform signal
refers to this
Waveform signal captured
indicator icon： Trigger
Coarse adjustment/
fine adjustment
��% Micro
50%
