Fnirsi 2C53P Manual page 32

②Waveform selection paging：
③Run/Pause： Clicking on this button can switch between signal running and pausing.
④Frequency： Specific parameters can be set by inputting values with the buttons, with a maximum of 【10 000 000】 .
Clicking on 【Confirm】 is required for the settings to take effect.
⑤Amplitude： Clicking on this can set specific parameters by inputting values, with a maximum of 【3.0V】 ， Clicking on
【Confirm】 is required for the settings to take effect, and adjustment can also be made by sliding on the right.
⑥Duty cycle： Clicking on this can set specific parameters by inputting values, with a maximum of 【100%】 ， Clicking on
【Confirm】 is required for the settings to take effect, and adjustment can also be made by sliding on the right.
⑦Value input area： Selecting 【Frequency】 , 【Amplitude】 , or [Duty cycle]allows for inputting specific values, which will
take effect after clicking on 【Confirm】 .
2.2 Signal Generator Parameters
Different Waveform Output Frequencies
Waveform Frequency
Waveform Amplitude
Square Wave Duty Cycle
Clicking on 【Previous】 、 【Next】 can switch to display other waveforms for selection.
Sine wave: 10MHz, other waveforms 5MHz
0-10MHz
0.1V-3.0V
0-100%
