Introduction

ST SPC58 (Chorus) 2B Line Emulation Adapter primary use case is providing Nexus trace
functionality for the SPC58 2B Line devices in the QFP64 and the QFP100 packages, where Nexus
trace port is not available.
The Emulation Adapter might differ in some peripherals from the target device; therefore,
the device datasheet should be checked.
The Emulation Adapter is based on the 144-pin "superset" device and provides the adaptation to
64-pin and 100-pin QFP target package.
The Emulation Adapter can also be used as a standalone device for microcontroller evaluation
purposes or for development and test of an embedded application ahead of target board
availability.
ST SPC58 2B Line Emulation Adapter is based on the SPC582B60E5 device in the QFP144
package, only in which the Nexus trace port is exposed and available. It's a "superset" device with
1MB program flash and can emulate all ST SPC58 2B Line devices in smaller packages.
Complete Emulation Adapter is split into individual parts which makes it flexible when support for
different target packages is required. A typical setup in conjunction with the target contains:
·
IEA-SPC582B (Microcontroller part)
·
Conversion board
·
Solder part
