Introduction

ST SPC58 (Chorus) C Line Emulation Adapter primary use case is providing Nexus trace func-

tionality for the SPC58 C Line devices in the QFP packages, where Nexus trace port is not avail-

able. The emulation adapter is based on the 292-pin "superset" device and provides the adapta-

tion to

64-pin

100-pin

144-pin

176-pin QFP package Adaptations.

The Emulation Adapter might differ in some peripherals from the target device; there-

fore, the device datasheet should be checked.

Alternative use case is a

application while the target not be available yet.

ST SPC58 C Line Emulation Adapter is based on the SPC58EC80 device in the BGA292 package,

only in which the Nexus trace port is exposed and available (P1 connector). It's a "superset"

device with 4MB program flash and can emulate all ST SPC58 C Line devices in smaller pack-

ages.

Complete Emulation Adapter is split into individual parts which makes it flexible when support

for different target packages is required. A typical setup in conjunction with the target contains:

IEA-SPC58EC (Microcontroller part)

Conversion board

Solder part
