Introduction

Galvanic isolation is used where two electric circuits must communicate, but their grounds may be
at different potentials. It is an effective method of breaking ground loops between the two circuits.
Galvanic isolation is also used for safety, preventing accidental current from reaching ground
through a person's body.
iSYSTEM Galvanic Isolation Adapters provide a basic isolation that withstands high voltages.
To prevent injury to personnel when dealing with potentially hazardous voltages it is mandatory to
have a second protection measure in place, in case the first insulation barrier fails. This is termed
double or, reinforced isolation. How should a double isolation be implemented depends on the use-
case or application setup.
It is your responsibility to check the local safety directives applicable to your company and
country to ensure that all requirements are met.
MPC5xxx / SPC5 14-pin 2.54 mm Galvanic Isolation Adapter is used to electrically isolate:
iSYSTEM iC5700 BlueBox in conjunction with
·
14-pin 2.54 mm MPC5xxx Debug Adapter
o
o MPC5x/SPC5x Aurora Active Probe MPC5x/SPC5x Aurora Active Probe (Ordering code
IC57150) + 14-pin 2.54 mm JTAG Converter (Ordering code IASAM34MPCPIN14)
from the embedded target.
More information about our products on
(Ordering code IC50150) or
www.isystem.com or via sales@isystem.com.
