2.3

RIGGING

NOTICE
NOTICE
Please follow the European and national guidelines for safe rigging and trussing.
2.4

SAFETY SYMBOLS

Symbol Meaning
Read the manual carefully before use!
Warning: Flammable Fluid. There's flammable
fluid inside the 100L tank, the internal machine
pipework, the connection hoses and projected
from the flame outlet.
Warning: High Pressure. There's high pressure
liquid inside the internal machine pipework, the
connection hoses and projected from the flame
outlet.
Warning: High Voltage. There's high voltage on
the ignition probes in the flame head nozzle
during operation.
2.5

SAFETY PRECAUTIONS

CAUTION
18 MAGICFX LIQUID FLAME SYSTEM
Make sure that fuel hoses and cable runs are well supported,
and are clear from obstructions and sharp edges. Always
support hanging hoses with strain reliefs. Avoid hard bends and
kinks. Failure to do so, could result in damaged hoses and
cables.
Make sure that fuel connections do not carry the weight of the
connected fuel hoses. Failure to do so, could result in leaking or
damaged fuel connections.
Make sure that supporting surface for the PUMP STATION is level,
solid, and that it can support the weight of a fully fueled PUMP
STATION (278.5 kg). If the PUMP STATION is not installed in level
position, fuel may leak from the air vent.
— User and Installation Manual
®
Position
Front of the
machine.
Front of the
machine.
Front of the
machine.
Top of each flame
head, near the
flame outlet.
Safety symbols
