- Page 2 PRODUCT CODE : MFX0350 VERSION : 1.0 DATE : 26.02.2013...
-
Page 3: Congratulations
1995. All our products are made under the brand name MAGICFX® which by now has acquired a great reputation on account of its quality and reliability. All products are made in accordance with the European Machinery Directive. MAGIC FX manages the entire production process in-house, from the design stages and prototyping to production. -
Page 4: Ce Marking
Unauthorised removal of safety caps and/or safeguards. Incompetent operation of the machine. MAGIC FX B.V. is not liable for any consequential loss in the event of a Shot Base DMX breakdown. © Copyright 2012 All rights are reserved. Nothing from this manual may be duplicated, or kept in an automated data file, or made public, or in any form or manner, whether electronically, mechanically, by photocopying, by incorporation, or in any other manner duplicated without the permission of MAGIC FX B.V. -
Page 5: Declaration Of Conformity
User documentation MAGICFX® Shot Base DMX 3. DECLARATION OF CONFORMITY DECLARATION OF CONFORMITY (according to Annex II.1.A of the Machinery Directive) Concerning the Machinery Directive. We; MAGIC FX B.V. Schouwrooij 27 5281 RE Boxtel The Netherlands State under personal responsibility: We are the manufacturer of the product: ®... -
Page 6: Foreword
MAGIC FX advises that the original of this user manual, including appendices, is kept at a safe and central place. It is best that another original or copy is kept close to the Shot Base DMX at the workplace. -
Page 7: Table Of Contents
CONGRATULATIONS! ..................1 CE MARKING ....................2 DECLARATION OF CONFORMITY ..............3 FOREWORD ....................4 INTRODUCTION ....................6 DESCRIPTION AND APPLICATION OF THE SHOT BASE DMX ........6 NECESSARY ACCESSORIES ....................6 CANNONS ..........................6 SAFETY ......................8 INTRODUCTION ........................8 GENERAL SAFETY RULES .................... -
Page 8: Introduction
The Shot Base DMX runs on 230V~50/60Hz and is controlled by DMX-512. As the Shot Base DMX can be used in various ways, it is important to read this user manual carefully from beginning to end before you start operating the machine. - Page 9 User documentation MAGICFX® Shot Base DMX The following types of electric cannons are possible: TYPE CANNON CONTENT CANNON LENGTH OUTPUT CONFETTI (150g) 40CM STREAMERS (150g) 40CM CONFETTI (300g) 80CM STREAMERS (300g) 80CM Table 5.3 All pre-filled cannons are for one-off use only.
-
Page 10: Safety
Make sure that children, unauthorised people and animals do not obtain access to the Shot Base DMX! Do not take hold of the Shot Base DMX while it is working or is switched on. Also, when the Shot Base DMX is not working, the electric cannon may still be filled. -
Page 11: Warnings
User documentation MAGICFX® Shot Base DMX WARNINGS Warning texts have been attached to the Shot Base DMX. With regard to these the following rules apply: These texts may not be removed or damaged. The operator must regularly check if this is the case. -
Page 12: Parts
Version 1.0 7. PARTS 13 14 1. Power switch 10. UP button 2. Power input 11. DOWN button 3. Power output 12. RESET button 4. DMX input 13. Cannon connection 5. DMX output 14. Indicator LED 6. Warning LEDs 15. Turning lock 7. -
Page 13: Accessories
F. +31(0)411 63 50 12 W. http://www.magicfx.eu E. info@magicfx.eu 9. PREPARATIONS Unpack the Shot Base DMX. Dispose of the packaging material without harming the environment. Inspect the machine for any damage. If damage is noticed this must be reported to MAGIC FX. Page 11... -
Page 14: Installation
The machine can be damaged if you do not follow the procedures carefully. DANGER WARNING: The MAGICFX® Shot Base DMX may only be installed by adults and authorised persons. Prepare the Shot Base DMX for use as follows: If you want to use the Shot Base DMX in a... - Page 15 The Shot Base DMX runs on 230V~ 50/60Hz. You will need a powerCON plug to be able to provide the Shot Base DMX with electricity. The Shot Base DMX is also equipped with a powerCON output.
- Page 16 DMX controller and that these channels are in the safe mode. The safe mode means that during the installation of the Shot Base DMX the 0-values of a channel are set. Consult the manual of the DMX controller for the set-up.
- Page 17 User documentation MAGICFX® Shot Base DMX Now the address behind Output 1 will start flashing on and off. You can set this in the same way as the Safety address. If at the first setting you have opted for Set...
-
Page 18: Usage
The MAGICFX® Shot Base DMX may only be installed by adults and authorised persons. The Shot Base DMX may only be operated if all parts are completely and correctly installed/connected. For using the Shot Base DMX take the following steps: Load the Shot Base DMX with the cannons you have selected. - Page 19 To get the Shot Base DMX out of the safe mode, the ‘safety’ channel on the Shot Base DMX must be set between 40% and 60%.
-
Page 20: Switching Off
Version 1.0 12. SWITCHING OFF To switch off the Shot Base DMX, take the following steps: Make sure that the Shot Base DMX is in the safe mode. Switch off the Shot Base DMX by pressing the electricity switch in the ‘off’... -
Page 21: Troubleshooting
The Shot Base DMX is still malfunctioning after troubleshooting Always contact your dealer or the technical service of MAGIC FX first in case of uncertainties, questions about the Shot Base DMX works or other issues with regard to the Shot Base DMX. Page 19... -
Page 22: Technical Specifications
Design and product specifications can be changed without prior notification. 15. MAINTENANCE To achieve the maximum service life of the Shot Base DMX you must regularly clean the Shot Base DMX and test if it is working correctly. Should the Shot Base DMX not work for some reason then please contact MAGIC FX.
