NOTICE
1.4

FUEL

The LIQUID FLAME SYSTEM uses two types of fuel to create the effect. The fuel is loaded
via the fuel fill cap at the fluid fill point, or with the external filling pump.
NOTICE
CAUTION
1.5

ACCESSORIES

Code Product
MFX3223 Terminator
MFX0347 External filling pump cable - 10 m
MFX0348 External filling pump cable - 20 m
MFX1474 Fuel distribution block (only for FLAMEBLAZER heads)
Fuel hose 3/8" OR 5/8" (1/2" OR 1/4" coupling) -
MFX147x
5/10/20/30/50 m
Please contact MAGIC FX for additional possibilities.
For information about the accessories of the ARM CONTROLLER (MFX3220), refer to the
ARM CONTROLLER User and Installation Manual (PART01882). For information about
the accessories of the flame head, refer to the corresponding user and installation
manual. See Other documentation on page 11.
For more information on the liquid flame system components,
please refer to the manuals of the flame heads.
Only use these types of fuel: Isopropanol, ISOPAR G, H & L. The use
of other fuels or water may degrade the performance of the
machine or cause internal damage.
Fuels are highly flammable and must be handled with caution
and in accordance with local health and safety regulations.
Always follow the safety instructions from the fuel packaging
when handling and working with the fuel.
MAGICFX LIQUID FLAME SYSTEM
— User and Installation Manual
®
Included
Accessories
11
