Power Drain - Magicfx LIQUID FLAME SYSTEM User And Installation Manual

POWER DRAIN

1. Connect a drain hose to the drain output.
2. Ensure the system is powered on.
3. Move the fuel drain valve to the power drain position.
4. Press and hold the fuel drain button.
5. Direct the flow of liquid into a suitable container.
6. Let go of the fuel drain button when finished.
7. Close the fuel drain output.
8. Disconnect the Fuel Drain hose.
WARNING
26 MAGICFX LIQUID FLAME SYSTEM
Fuels are highly flammable and must be handled with caution
and in accordance with local health and safety regulations.
Always follow the safety instructions from the fuel packaging when
handling and working with the fuel.
— User and Installation Manual
®
