Menu function
Reset Errors
DMX Enable
Address (1-512)
RDM (ON/OFF)
DMX over ARM
(ON/OFF)
Sort by DMX/Serial
(SN/DMX)
Sequential
Addresses (ON/OFF)
XXXXX HEAD (start
address 1-512)
Lock tilt heads (ON/
OFF)
Display Dimmer
(On/Off)
Factory Defaults
(Yes/No)
Type
(Alarm/Error)
Serial Number
Unique ID
(HHHHHHHHHHHH)
Software Version
Software CRC
Bootloader CRC
Build Date
Uptime
(DDDD:HH:MM:SS)
Pump Runtime
(DDDD:HH:MM:SS)
Explanation
In case there is a locking error present, this button will reset the
appliance. If the fault does not persist, the locking error will not
reappear.
Setting the DMX Enable Address for the PUMP STATION.
Use this function to turn on/off the RDM functionality.
If a combined DMX and ARM signal is used, set this option to
ON. If the DMX signal runs separately, set this option to OFF.
Make sure the DMX over ARM settings match your wiring setup.
Sort connected head based on their serial number (SN) or
based on their DMX start addresses (DMX).
Enabling this will update all head addresses in sequential order
when changing the start address of a head.
Set the start address of a head. XXXXX displays the serial
number of the head (e.g. 12345), while HEAD displays the head
type (e.g. HELLFIRE, FLAMEBLAZER).
Use the lock tilt to lock the angle position of all connected
heads. The head and pump will display an error when the head
tilts more than 5 degrees from the locked position. The error is
cleared when the head repositions itself to within the range.
When this function is OFF, the error will only display when the tilt is
outside given bounds.
Turn display dimmer on or off. If turned on, the display is dimmed
automatically 30 seconds after the last button push.
Restores the appliance factory default settings.
Toggle between the occurred locking error (Alarm) list, and
blocking error (Error) list. Locking errors need intervention by
user, although they are "auto-reset" 3 times before the appliance
remains in error until reset by user. Blocking errors clear when the
triggering fault disappears. 16 locked, and 16 blocked errors are
logged. Top of the list shows the last occurring error.
Appliance serial number as also printed on the appliance label.
UID number as the appliance appears in the RDM device list
after running discovery.
Installed software version.
CRC of the functional software.
CRC of the bootloader software.
Release date of functional software.
Time counter which indicates how long the appliance has been
powered in total.
Time counter which indicates how long the effect has been on in
total.
