STEP 10:
Locate the U-Shape metal support bracket QB1350. Attach this to one of the cabinet's back using
two AA6227 bolts with washers on the inside of the bracket and on the inside of the cabinet use two
PC60604 nylon nuts. Do not tighten the bolts holding the bracket at this time.
2X AA6227
2X AA6075
2X PC60604
Only tighten the front hardware
holding the bar to the cabinet.
Note - Bolts can be installed either way.
