Washers
Remove the Clamping Plate, Washers (x2), and the Hand
3.
Knob from the Desk Clamp.
Insert the Clamping Plate back onto the Hand Knob.
4.
(Figure 6)
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Hand Knob
Figure 5
Figure 6
8
Screw
Clamping Plate
