FRONTALS
INFINITY Drawer Guide
INFINITY DRAWER ADJUSTMENT
Left and Right Adjustment
Turn the screw shown to adjust the drawer frontal left & right.
Repeat on both sides.
Up & Down Adjustment
Turn the screw shown to adjust the drawer frontal up & down.
Repeat on both sides.
Lock Position
Tighten the screw shown to lock the drawer frontal in position.
Repeat on both sides.
Remove Frontal
To remove the frontal, release the fixing clip by turning the locking plate screw
shown.
Repeat on both sides.
For Internal Use: _CON.INS.014.001_INFINITY_DRAWER_GUIDE_Rev2
Page 3
Page 3
