Summary of Contents for Wren 1000 2 Drawer
- Page 1 BASE UNIT 1000 2/3 Drawer Assembly Guide 1000 2 Drawer 1000 3 Drawer For Internal Use: FI.WR.INS.027_WKIN00111_BASE_1000_2_3Drawer_Rev4.indd...
- Page 2 BASE UNIT BASE UNIT BEFORE YOU START 1000 2/3 Drawer 1000 32/3 Drawer INSTALLATION SHOULD BE PERFORMED BY A Assembly Guide Drawer Assembly COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Standard Drawer (Packed Separately) Fitting Pack Contents Metal Back Panel (J) x16 (N) x1...
- Page 3 BASE UNIT BASE UNIT Step 1. Secure drawer base to drawer side using 4 x 16mm 1000 2/3 Drawer 1000 2/3 Drawer drawer runner screws (J) in holes provided. Drawer base Assembly Guide Standard Drawer Seat the edge of drawer base tight Assembly into corner of casing, as shown.
- Page 4 BASE UNIT Step 1. BASE UNIT Secure drawer base to drawer side using 4 x 16mm 1000 2/3 Drawer 1000 2/3 Drawer drawer runner screws (J) in holes provided. Drawer base Assembly Guide Deep Drawer Seat the edge of drawerbase tight into corner ofcasing, as shown.
-
Page 5: Assembly Guide
BASE UNIT BEFORE YOU START 1000 2/3 Drawer INSTALLATION Assembly Guide SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel A Panel E Panel C Panel B x1 Back Panel x1 Base Panel x2 Rail Panel x2 End Panel (F) x12... - Page 6 BASE UNIT Drawer runner bracket screw position 1000 2/3 Drawer Assembly Guide 37mm 261mm 431mm 74mm 2 drawer Step 1. from base To attach drawer runner 646mm screw into end panels (B) using 2 x 16mm screws (J) per drawer rail, into pilot holes provided, 3rd hole from front, as shown.
- Page 7 BASE UNIT 1000 2/3 Drawer Step 2. Carcass Assembly Seat dowels (F) into holes in Seat (G) panels as shown. cam dowel into hole as shown Step 3. Seat cam dowels (G) into holes in panels as shown. Dowel (F) &...
- Page 8 BASE UNIT 1000 2/3 Drawer Carcass Assembly Step 6. Slide back panel (A) into groove of end panels (B). Once back panel (A) is in position, ensure the panel is flush & square with bottom of end panels (B). Step 7. Hand tighten all cam locks (H), this will expand cam dowels (G) and tighten the unit together.
- Page 9 BASE UNIT 1000 2/3 Drawer Front Assembly Guide Step 9. Secure each of the legs into place with 2 x 15mmscrews (L) per leg Ensure legs are rotated as shown so that part of it is supporting the end panels (B). Front legs should have flat edge to the front.
- Page 10 BASE UNIT Secure unit to wall using space plug. 1000 2/3 Drawer Drill pilot hole through the back brace into the wall and insert Assembly Guide wall plug. Then unwind space plug until it contacts both surfaces. Finally, tighten the screw. Screws for attaching to walls are not provided as these vary depending on your wall material and...
- Page 11 BASE UNIT 1000 2/3 Drawer Carcass Assembly Page 10...
