DRAWER BOX
ADJUSTMENT, REMOVAL
INFINITY
Tools required:
Cross head screwdriver
Up & Down Adjustment.
Turn screw shown to adjust drawer frontal up & down.
Left & Right Adjustment.
Turn screw shown to adjust drawer frontal left & right.
Fit Cover Caps.
Fit drawer cover caps over drawer side adjustment. Position the edge
closest to the frontal first. Position the far side edge into place. Press
the cover cap against the drawer side to secure it in place. Repeat on the
opposite side.
For Internal Use: FI.WR.INS.135_WBIN00031_Infinity_DrawerBox_Rev1
Page 1
