BASE UNIT
800 & 1000
Adjustable Corner
800/1000
800/1000 Magic
1000 Cornerstone
Corner Option
Tray Option
For Internal Use: FI.WR.INS.023_WKIN00105_BASE_Adj_Cnr_800 -1000_2Dr_Rev2.indd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wren 800

  • Page 1 BASE UNIT 800 & 1000 Adjustable Corner Assembly Guide 800/1000 800/1000 Magic 1000 Cornerstone Corner Option Tray Option For Internal Use: FI.WR.INS.023_WKIN00105_BASE_Adj_Cnr_800 -1000_2Dr_Rev2.indd...
  • Page 2 BASE UNIT BEFORE YOU START 800 & 1000 INSTALLATION SHOULD BE Adjustable Corner PERFORMED BY A COMPETENT Assembly Guide PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Legs Panel A Panel B Panel C Panel D Panel E...
  • Page 3 BASE UNIT 800 & 1000 Step 1. Adjustable Corner Seat dowel (F) into holes in Assembly Guide Seat (G) both end panels (B) cam dowel into hole as as shown. shown. Step 2. Seat cam dowel (G) into holes in both end panels (B) as shown.
  • Page 4 BASE UNIT 800 & 1000 Adjustable Corner Assembly Guide Step 5. Slide back panel (A) into groove of end panels (B). Once back panel (A) is in position, ensure the panel is flush & square with bottom of end panels (B).
  • Page 5 BASE UNIT Adjustable Corner Post Pack 800 & 1000 Adjustable Corner Panel X x 1 Assembly Guide Panel Y x 1 Packer Z x 2 Step 9. Place packer (Z) flush with the front edge of the cabinet and up tight to the centre muntin.
  • Page 6 BASE UNIT 800 & 1000 Step 12. Adjustable Corner Corner Blanking Panel Assembly Guide Measure and cut blanking panel to required width. Step 13. Secure blanking panel with 9 x 15mm screws (L), evenly spaced, as shown. Ensure you screw in the centre of panels (9mm from edge).
  • Page 7 BASE UNIT 800 & 1000 Step 14. Adjustable Corner Secure each of the Assembly Guide legs into place with 2 x 15mm screws (L). Front Ensure legs are rotated as shown so that part of it is Front supporting the end panels (B).
  • Page 8 BASE UNIT 800 & 1000 Adjustable Corner Carousel Tray Assembly Guide Please refer to separate instructions included with your carousel tray. The middle shelf should be discarded when using the carousel tray. 1000 Carousel Page 7 For Internal Use: FI.WR.INS.023_WKIN00105_BASE_Adj_Cnr_800 -1000_2Dr_Rev2.indd...
  • Page 9 BASE UNIT 800 & 1000 Adjustable Corner Magic Corner Assembly Guide Please refer to seperate instructions included with your magic corner. The middle shelf and hinges should be discarded when using the magic corner. For Step 1 in the Magic Corner Instructions.
  • Page 10 BASE UNIT 800 & 1000 Adjustable Corner Assembly Guide Hinge Mounting Plate Attach hinge plates onto panel (D) in locations shown using 4 x 15mm screws (L). (Ignore this step when fitting Magic Corner) Securing to Adjacent Units Screw into any side units using the screws (L) provided to secure to unit.
  • Page 11 BASE UNIT THE FOLLOWING STEPS ARE NOT REQUIRED FOR BIN UNITS Step 17. 800 & 1000 Adjustable Corner Insert hinge in top & bottom holes as shown. Assembly Guide Hinges Step 18. Secure hinges by tightening 2 x screws with hinge dowels attached.
