3.7 Terminal Description

A
Position
A
B
C
D
E
F
G
H
I
J
Note: The image shown here is for reference only. The actual product received may differ.
B C
Figure 3. Terminals on the inverter
DC Switch
PV Input Terminal (The terminal number depends on inverter model)
Grid Terminal for connection to the utility grid
Multi COM(Communication) Terminal for CT, EV charger, Dry and meter
DRM Terminal block for connecting to a demand response enabling device
(DRED).
BMS Communication Port for communication between the inverter and the
Li-Ion battery.
AC Terminal for backup loads
Communication Port for Wi-Fi Stick
Battery Input Terminal (BAT+/BAT-)
Additional grounding terminal
D
G
Description
10
E F
H I J
