Assembly — Hanging the Fan (continued)
9
Installing the canopy
WARNING: Make sure the tab on the mounting bracket (A)
properly sits in the groove in the hanger ball/downrod
assembly (D) before attaching the canopy (B) to the mounting
bracket (A) by turning the canopy (B) until it drops into place.
NOTE: Adjust the canopy mounting screws (EE) as necessary
until the canopy (B) and canopy bottom cover (C) are snug.
□
Make sure connections are neatly tucked into the
ceiling outlet box.
□
Slide the canopy (B) up to the mounting bracket (A) and
place the key holes on the canopy (B) over the loose
canopy mounting screws (EE) on the mounting bracket
(A). Turn the canopy (B) clockwise until it locks in place
at the narrow section of the key holes, and tighten the
two canopy mounting screws (EE).
□
Attach the canopy bottom cover (C) to the canopy (B) by
inserting the screw heads into the key slots in the canopy
bottom cover (C) and rotating it clockwise.
Assembly — Attaching the Fan Blades
10
Attaching the remaining fan blade
WARNING: To reduce the risk of personal injury, do not
insert foreign objects between rotating fan blades (G).
□
Bring the remaining fan blade (G) up to the motor and
use the blade support plate (H) to secure it in place.
EE
D
C
11
Please contact 1-800-986-3460 for further assistance.
Outlet Box
A
EE
B
H
HOMEDEPOT.COM/HOMEDECORATORS
G
