USE AND CARE GUIDE
SARINA 23-INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection SARINA CF1004B
Summary of Contents for Home Decorators Collection SARINA CF1004B
- Page 1 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday. 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS THANK YOU to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Home Decorators Collection!
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............2 Assembly................7 Safety Information ............... 2 Operation ................10 Warranty ................3 Care and Cleaning............. 12 Pre-Installation ..............4 Troubleshooting..............13 Installation................6 WARNING: To reduce the risk of personal injury, do not bend the blade brackets (also referred to as 1. -
Page 3: Safety Information
"wobble" is normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. Home Decorators Collection hereby disclaims any and all warranties, including but not limited to those of merchantability and tness for a particular purpose to the extent permitted by law. -
Page 4: Pre-Installation
Pre-Installation SPECIFICATIONS Gross Size Speed Volts Amps Watts Cu. Ft. Weight Weight 0.09 9.26lbs 18.25lbs 1300 23.6 in. 0.13 2.237 (4.2 kg) (8.28 kg) 0.14 1800 NOTE These are approximate measures. They do not include the amps and wattage used by the light kit. TOOLS REQUIRED 5003280 Phillips... - Page 5 Pre-Installation (continued) ON / OFF ON / OFF 3 SPEED BRIGHTNESS NIGHT LIGHT COLOR TEMP. TIMER SUMMER WINTER FAN DIRECTION HOLD 3 SEC. Part Description Quantity Mounting bracket Hanger rod Canopy Coupling cover Fan-motor assembly IR remote (batteries included) Remote bracket base Remote bracket hitch pin (pre-installed) lock pin (pre-installed)
-
Page 6: Installation
Installation MOUNTING OPTIONS Hanger Bar WARNING: personal inju ry, mount to outlet box marked “A cceptable for fan suppor t of 35 lbs. (15.9 kg) or less”, and use screws provided with the outlet box. An outlet box not be acceptabl e for fan supp ort and may need to be Outlet Box If your ceiling fan does not have an existing UL-listed outlet box, then install one using the following instructions:... - Page 7 Assembly - Hanging the Fan Install the mounting bracket to Prepare the down-rod assembly ceiling □ Remove the hitch pin (I) and lock pin (J) from the bottom of WARNING: To reduce the risk of re, electric shock, or other hanger rod (B).
-
Page 8: Assembly
Assembly - Hanging the Fan (continued) Attaching fan-motor assembly to Connecting the wires the down-rod assembly □ □ Pre-lock two combination screws (AA) into two Carefully lift the whole xture to hang the ball head of hanger opposite holes on the outer race of the coupling cover (D). rod (B) onto the mounting bracket (A) previously installed on Align two pre-locked combination screws (AA) with two ceiling. - Page 9 Assembly - Hanging the Fan (continued) Install the canopy Install the remote bracket □ Using the remote bracket base (G) as a guide, mark the two holes □ Align two key holes of canopy (C) with the pre-installed locations. screws under the mounting bracket (A). Push up the canopy (C) □...
-
Page 10: Operation
Remote Operation Remote control Warm weather Your fan is equipped with a remote control to operate the speed and lights for your new ceiling fan. effect. This allows you to set your air conditioner on a warmer setting without affecting your comfort. ceiling. - Page 11 Remote Operation Icon Button Name Action Notes Press different buttons will light up 3 Speed LED different quantity of indicators All ON/OFF press to turn the Fan and light on/off Press once to turn the fan on Press again to turn the fan off ON / OFF ON / OFF Fan ON/OFF...
-
Page 12: Care And Cleaning
Care and Cleaning WARNING: Make sure the power is off before cleaning your fan. □ Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling. □... -
Page 13: Troubleshooting
Troubleshooting Problem Solution The fan will not start. 1. Check to make sure the wall switch is in the on position if applicable. 2. Check the main and branch circuit fuses or breakers. 3. Make sure your device is connected to a power source. 4. - Page 14 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
