6. HANGING THE FAN

REMEMBER to turn off power at the breaker.
Follow the steps below to hang your fan properly:
1. Disconnect power at the breaker to the fan location. A licensed
electrician must install the fan. (Fig. 5)
2. Remove 1 of 2 screws from the bottom of mounting bracket and
save for use in section 9. Loosen the other screw. (Fig. 6)
3. Unscrew the four mounting neck screws to separate the mount-
ing bracket from the mounting neck. (Fig. 7)
4. Remove stop valve from the neck of the mounting bracket by
loosening the two stop bracket screws on the neck of the mount-
ing bracket in 1/4" from the screw head.
FR -W 1 8 0 5
FIGURE 5
FIGURE 6
Mounting Neck
Screws
Stop Valve
Screws
FIGURE 7
Mounting
bracket
Screw
Mounting
Bracket
Mounting Neck
Stop Bracket
