INSTALLING THE LED LUMINAIRE MODULE (cont.)
5.
If installing the optional metal light cover, make sure it is securely
tightened. (Fig. 21)
NOTE: Add metal light cover if you do not need lighting function or prefer a
different aesthetic. (Fig. 21)
NOTE: Do not connect the LED connector wires if you are using the metal
light cover.
FR - W 1 8 0 5
Metal light cover
FIGURE 21
19
