Modern Forms F-RCBT-WT Operation Instructions

OPERATION INSTRUCTIONS
Package Contents
Screws
Remote Wall Cradle
1
Pairing
NOTE: Pairing must be completed within three (3) minutes of
turning the power ON to the fan receiever.
To pair your remote control:
1. Power cycle your fan by removing power from the circuit
breaker for 10 seconds and then re-enable power.
2. Press and hold
for 4-5 seconds.
F-RCBT-WT
3. The LED will blink green.
4. The green LED along with audible beeps will indicate that
pairing is successful.
5. Test remote control using the steps in section 2.
Remote Control Operation
2
CR2032
FIG.2
CR2032
NOTE: Your fan features 6 speeds. An audible tone will
Batteries
indicate when the speed is increased or decreased. When
the fan has reached the minimum/maximum speed level
the fan will beep twice.
and buttons on remote control
Press and Hold
FIG.1
NOTE: A maximum of 10 remote controls or wall
controls can be used with a fan.
Remote Control Button Functions
button: Turns the light ON or OFF.
Press or hold to increase the light level.
Press or hold to decrease the light level.
button: Turns the fan ON or OFF.
Press or hold the button to increase fan speed.
Press or hold the button to decrease fan speed.
button: Switch between Summer and Winter Mode.
SUMMER MODE (Counter-Clockwise):
A downward airflow creates a cooling
effect (FIG. 3). This allows you to set
your air conditioner on a warmer
setting without affecting your comfort.
FIG.3
WINTER MODE (Clockwise):
An upward airflow moves
warm air off the ceiling area and
re-distributes the warm air that hovers
around the ceiling to the living space.
This should allow for savings on
FIG.4
heating costs (FIG. 4).
NOTE: On your fan, press the button while the fan is running
Breeze Mode
3
1. Breeze Mode mimics the natural ebb and flow
of winds in nature by varying the fan speed.
NOTE: Breeze Mode always rotates your fan
in the Summer (CCW) direction
2. To start Breeze Mode, press
for 4 seconds. The LED will blink green
and the fan will beep.
3. To exit Breeze Mode and return to standard
fan mode, press and for 4 seconds.
The led will blink green and the fan will beep.
Your fan will return to the direction and speed
it was set to prior to entering Breeze Mode.
and
