6. HANGING THE FAN (cont.)
1.
Slip the coupling cover, canopy screw cover (painted side face
down), and canopy (opened side up) onto the downrod. (Fig. 10).
Coupling cover goes all the way to the bottom.
2.
Carefully reinstall the hanger ball onto the downrod, being sure
that the cross pin is in the correct position, the setscrew is
tightened and wires are not twisted. (Fig. 10)
FR -W 1 8 0 5
Motor wires
Downrod
Coupling Cover
FIGURE 10
Safety cable
Canopy
Canopy
screw cover
10
