- Page 1 Digital/Analog Audio Converter with Dolby Digital Decoder - # 15356 Operation Manual...
- Page 2 Introduction The Universal Digital/Analog Audio Converter with Dolby Digital decoder is designed to convert audio between Optical, Coaxial and analog audio formats. With the ability to convert digital signals into analog and analog signals into digital, this device supports the simultaneous conversion of audio formats allowing you to choose between optical, coaxial or analog or all three at the same time.
-
Page 3: Power Led
Operation Front Panel Controls and Functions POWER LED: The LED will illuminate blue when connected to power and in red when switched off. Dolby Digital LED: The LED will illuminate when the the audio source is Dolby Digital encoded. L/R IN LED: The LED will illuminate blue to indicate that the L/R input is selected. -
Page 4: Optical Out
Left Panel L/R OUT: Connect to the analog (L/R) audio input of the audio system such as a TV or amplifier with a stereo RCA cable. COAX OUT: Connect to the audio system's coaxial input. OPTICAL OUT: Connect to the audio system's optical input. Rear Panel DC 5V: Connect the 5V/1A DC power supply to the unit and plug the adaptor to an... - Page 5 Specifications Input Ports 1×Optical, 1×Coaxial, 1×Analog Stereo (L/R) Output Ports 1×Coaxial, 1×Optical, 1×Analog Stereo (L/R) Optical/Coaxial Input LPCM 2CH & Dolby Digital Audio Formats Audio Sampling Rates 32~96kHz L/R Input Impedance 47KΩ L/R Output Impedance 600Ω ESD Protection Human body model: ±10kV (air-gap discharge) ±6kV (contact discharge) Power Supply...
- Page 6 Connection Diagram...
