- Page 1 UHD Matrix 4in 2out HDCP 2.2 - # 15385 Operation Manual...
- Page 2 Introduction The 6G UHD 4 by 2 HDMI Wall Plate Matrix is the most advance HDMI solution for your true Ultra High-Definition signal distribution. It allows you to manipulate one 6G HDMI input signals with switching into two 6G HDMI displays simultaneously.
-
Page 3: Left Panel
Operation Top Panel Controls and Functions 1. POWER: Press the Power key to turn on the device and the LED will illuminated in green, press again to set it to standby mode and the LED will turn red. This device obtain power last memory function therefore, when power supply is re-plugged it will return to last power status. - Page 4 Right Panel 1. HDMI OUT A~B: Connect to HDMI TV / display or HD amplifier for output image and audio or audio display up to 6G each port. Bottom Panel 1. LAN: Connect to PC / Laptop with active internet service for Telnet / WebGUI control with RJ-45 terminated cable.
-
Page 5: Wall Plate
IR Cable Pin Assignment RS-232 Protocol Wall Plate Remote Controller Assignment Assignment ► ◄ Baud Rate: 19200bps Data bit: 8 bits Parity: None Flow Control: None Stop Bit : 1... - Page 6 RS-232 and Telnet Commands Command Description A 1~A 4 Switch output A to 1~4 B 1~B 4 Switch output B to 1~4 IPCONFIG Display the current IP config IPDHCP 0=Set IP mode to static, 1=Set IP mode to DHCP SIPADDR Set Ethernet IP address SNETMASK Set Ethernet netmask...
- Page 7 Once in the command line interface (CLI) type "telnet", then the IP address of the unit and "23", then hit enter. This will bring us into the unit which we wish to control. Type "help" to list the available commands. Note: Commands will be not executed unless followed by a carriage return.
- Page 8 Web GUI Control On a PC/Laptop which is connected to an active network system, open a web browser and type device’s IP address (factory default static IP: 192.168.1.50) on the web address entry bar. The browser will display the device’s control page for users to control. Specifications Video Bandwidth 600 MHz/6 Gbps...
-
Page 9: Connection Diagram
Connection Diagram... - Page 10 Supported Resolutions Resolution Input Output 640×480@60/72/75/85 √ √ 720×480@60 √ √ 720×576p@50 √ √ 800×600@60/72/75/ √ √ 1024×768@60/70/75 √ √ 1280×720@50/60 √ √ 1280×720p@60 √ √ 1280×768@60 √ √ 1280×800@60 √ √ 1280×1024@60 √ √ 1360×768@60 √ √ 1600×1200@60 √ √...
