Summary of Contents for Converters.TV 15389
- Page 1 HDMI Audio with Dolby Digital & DTS 2.0+Digital Out Decoder - # 15389 Operation Manual...
- Page 2 Introduction The HDMI Audio Converter with Dolby Digital and DTS 2.0+Digital Out ® ® Decoder allows the audio signal from an HDMI input to be de-embedded, downmixed and simultaneously output to both digital (optical or coaxial) and analog audio outputs. This unit allows you to utilize an additional audio output such as an AV receiver or set of active speakers, or to further extend the audio signal pathway Applications...
-
Page 3: Operation Controls And Functions
Operation Controls and Front Panel Functions 1. POWER: This LED will illuminate when the device is connected to an active power supply. PCM LED: This LED will illuminate when the input audio source is PCM format. DTS LED: This LED will illuminate when the input audio source is DTS 2.0+Digital Out encoded. -
Page 4: Video Bandwidth
For the HDMI output port, switch to 'BYPASS' to allow audio pass-through from HDMI input port; switch to '2CH' to enable audio decoding and 2- channel down-mixing for Dolby Digital or DTS audio signals from HDMI input port. SPDIF BYPASS/2CH: For the COAX and OPTICAL output ports, switch to 'BYPASS' to allow audio pass-through from HDMI input port;...
